Main Image
ST124PROGB
4 Port High Resolution SVGA Video Splitt
Split a single high resolution VGA video signal to 4 monitors or projectors
Main Image
Product Images
Product Images
Product Images
Product Images
Product Name 4 Port High Resolution SVGA Video Splitt Product Number ST124PROGB UPC 065030800280 Lifecycle status Discontinued Warranty 2 Years Taxonomy Product > Legacy Discontinued Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) XXXXXX066X Product Title (Short) 4 Port High Res VGA Video Splitter Product Title (Standard) StarTech.com 4 Port High Resolution VGA Video Splitter - 300 MHz - VideoView Pro 47 Port High Resolution 300 MHz Video Splitter - Video splitter - 4 ports Product Title (Long) 4 Port High Resolution VGA Video Splitter - 350 MHz Title Ingram (Part 1) 4 Port High Resolution VGA Video Title Ingram (Part 2) Splitter - 300 MHz Website Product Headline Split a single high resolution VGA video signal to 4 monitors or projectors Bullet 1 Allows 1 VGA video source to simultaneously display on 4 different monitors Bullet 2 Supports resolutions up to 2048x1536 @ 80Hz Bullet 3 High video bandwidth (350 MHz) Bullet 4 Daisy chainable for almost unlimited expansion Bullet 5 Maximum VGA cable length of 210ft (65m) Marketing Copy Applications - Create engaging multimedia presentations for demonstration in lecture halls and classrooms
- Display travel schedules and alerts in airports, bus terminals and train stations etc.
- Create eye-catching displays in trade-shows and auditoriums
- Use for in-store product merchandising in retail environments to give your advertisements greater visibility
- Get your message across multiple displays for trade-shows or information booths/kiosks
- Quick and easy solution to split a video signal in an auditorium or house of worship
Accessory Products - MXT101HQ
- MXT101HQ_100
- MXT101HQ_150
- MXT101HQ_200
- MXT101HQ_25
- MXT101HQ_50
- MXT105HQ
Related Products - ST124GB
- ST124LGB
- ST124WGB
Input Current 0.4A Input Voltage 110V-240V AC Output Current 2A Output Voltage (V) 5 DC Power Source AC Adapter Included Plug Type N Center Tip Polarity Positive Color Black Humidity 0~80% RH non-condensing Operating Temperature 5°C to 40°C (41°F to 104°F) Product Length (mm) 182 Product Width (mm) 80 Product Height (mm) 21 Product Weight (g) 1085 TAA Compliant No Bandwidth (-3db): 350MHz General Specifications Male to Female VGA extension cable required (MXT101HQ) Maximum Analog Resolutions 2048x1536 @ 80Hz Maximum Cable Length (mm) 65000 Industry Standards DDC compatible - all other monitors must be able to support the highest video resolution of the DDC-type monitor connected to Video Out 1 Regulatory Approvals FCC Part 15 Class A, CE Mark Carton Depth (mm) 405 Carton Height (mm) 315 Carton Quantity 12 Carton Weight Gross (g) 16000 Included in Package - 1 - 4 Port High Res. Video Splitter
- 4 - Rubber Feet
- 1 - Power Adapter
- 1 - Instruction Manual
Package Depth (mm) 184 Package Height (mm) 89 Package Width (mm) 238 Package Quantity 1 Package Weight (g) 1210 Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 VGA Connector 1 (Quantity) 4 Connector 2 VGA Connector 2 (Quantity) 1 Amazon Merchandising Manager Kathleen Marshall Artwork Due Date 2014-06-18 Enhanced Gallery Designer Rob Selenis en-US Content Approved Yes Graphic Designer Shane Arnett Launch Markets (concatenated) UK Primary Technology None Product Information Creation Specialist (PICS) Dan Dagenais Product Manager Rob Fleck Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Tech Lead Justin Weaver Technical Writer Andrew Richardson Technology Lifecycle Legacy
