Main Image
ST124W
4 - port Wall-Mount VGA Video Splitter
Split a VGA signal to 4 VGA monitors or projectors
Main Image
Product Images
BOM Image
Product Name 4 - port Wall-Mount VGA Video Splitter Product Number ST124W UPC 065030827522 Lifecycle status Discontinued Warranty 2 Years Taxonomy Product > Legacy Discontinued Country of Origin Europe & Japan China Country of Origin North America China Product Title (Short) 4 Port Wall Mount VGA Video Splitter Product Title (Standard) StarTech.com 4 Port Wall Mount VGA Video Splitter - Wall Mountable - Video splitter - 4 ports - cascadable Product Title (Long) 4 Port VGA Video Splitter - Wall Mountable Product Title (AMZ) 4 Port VGA Video Splitter with Power Adapter - Wall Mountable - Cascadable (ST124W) Title Ingram (Part 1) 4 Port Wall Mount VGA Video Spli Title Ingram (Part 2) tter Website Product Headline Split a VGA signal to 4 VGA monitors or projectors Bullet 1 Compact design with convenient topside connection Bullet 2 Lays flat or mounts on the wall Bullet 3 Supports resolutions up to 1600 x 1200 Bullet 4 Supports cable distances up to 65m / 210ft Bullet 5 250MHz video bandwidth Bullets (Consolidated) Video splitter - 4 x VGA - desktop Marketing Copy Applications - Use for in-store product merchandising in retail environments to give your advertisements greater visibility
- Display travel schedules and alerts in airports, bus terminals and train stations
- Create engaging multimedia presentations for demonstration in lecture halls and classrooms
- Get your message across multiple displays for trade-shows or information booths/kiosks
- Quick and easy solution to split a video signal in an auditorium or house of worship
Website Search Keyword - VGA Splitter
- VGA Video Splitter
- Video
- Wall-mount
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
Accessory Products - MXT101MMHQ
- MXT101MMHQ10
- MXT105MMHQ
- MXT101HQ
- MXT101HQ10
- MXT105HQ
- ST121UTP
- SVA9M2NEUA
Related Products - ST122L
- ST124L
- ST122W
- ST128L
- ST128W
- ST124PRO
- ST124PROA
- ST124SW
Constrained SKU Alternatives (Limited Stock) ST124PRO Equivalent Part Number in the EU ST124WEU Equivalent Part Number in the UK ST124WGB Output Current 0.3A Output Voltage (V) 9V DC Power Consumption (In Watts) 2.7 Power Source AC Adapter Included Center Tip Polarity Positive Color Black Material Plastic Operating Temperature 0°C to 50°C (32°F to 122°F) Product Length (mm) 105.000 Product Width (mm) 82.000 Product Height (mm) 28.000 Product Weight (g) 128.000 Storage Temperature -20°C to 60°C (-4°F to 140°F) TAA Compliant No Bandwidth 250MHz Maximum Analog Resolutions 1600x1200 Maximum Cable Length (mm) 65000 AV Input VGA AV Output VGA Industry Standards DDC (Pass-through supported on Port 1) Carton Depth (mm) 343 Carton Height (mm) 319 Carton Quantity 20 Carton Weight Gross (g) 6620 Included in Package - 1 - 4 Port VGA Splitter
- 1 - Instruction Manual
- 1 - Power Adapter
Package Depth (mm) 230 Package Height (mm) 56 Package Width (mm) 155 Package Quantity 1 Package Weight (g) 294 Packaging Description 4 Port Wall Mountable VGA Video Splitter Packaging Description India 4 Port Wall Mountable VGA Video Splitter Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 VGA Connector 1 (Quantity) 1 Connector 2 VGA Connector 2 (Quantity) 4 Amazon Merchandising Manager Kathleen Marshall Artwork Due Date 2014-06-18 Enhanced Gallery Designer Rob Selenis en-US Content Approved Yes Graphic Designer Shane Arnett Launch Markets (concatenated) CA,US Primary Technology None Product Information Creation Specialist (PICS) Dan Dagenais Product Manager Rob Fleck Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Tech Lead Justin Weaver Technical Writer Andrew Richardson Technology Lifecycle None
