ST20000SPEXI
2 Port PCIe 10G network adapter w Intel X540 chip
Add two 10 Gigabit Ethernet ports (10Gbps) to a client, server or workstation through one PCI Express slot
Main Image
Enhanced Images
Product Images
Product Images
Product Images
Video Link YouTube
Product Name 2 Port PCIe 10G network adapter w Intel X540 chip Product Number ST20000SPEXI UPC 065030860598 Lifecycle status End of Life Warranty 2 Years Taxonomy Product > Cards & Adapters > Network Cards & Adapters Category Level 1 Networking Category Level 2 Desktop and Server Network Cards Category Level 3 Ethernet Cards Family 10G PCIe Ethernet NICs - Copper Intel Country of Origin Europe & Japan Malaysia Country of Origin North America Malaysia Country of Origin History (1) China Country of Origin Revision (1) XXXXXX076X Country of Origin History (2) Malaysia Country of Origin Revision (2) XXXXXX156X Product Title (Ultra-Short) 2-Pt PCIe 10GbE NIC Product Title (Short) 2-Port PCIe 10Gb Ethernet Network Card Product Title (Medium) 2-Port PCI Express 10GBase-T Ethernet Network Card - with Intel X540 Chip Product Title (Standard) 10G Network Card – 2 port – NBASE-T – RJ45 Port – Intel X550 chipset – Ethernet Card – Intel NIC Card Product Title (Long) 2-Port PCI Express 10GBase-T Ethernet Network Card - with Intel X540 Chip Product Title (AMZ) 2-Port 10Gb PCIe NIC with Native Link Aggregation - 10Gbase-t Ethernet Card - 100/1000/10000 Mbps LAN Card (ST20000SPEXI) Title Ingram (Part 1) 2-Port PCIe 10G Network Adapter Title Ingram (Part 2) with Intel X540 Chipset Website Product Headline Add two 10 Gigabit Ethernet ports (10Gbps) to a client, server or workstation through one PCI Express slot Bullet 1 Add two 100/1000/10Gbase-T RJ45 ports, providing cost-effective network connectivity for high bandwidth workstations and servers Bullet 2 Intel X540 chipset with Intel® Virtualization Technology for Connectivity Bullet 3 Up to 20Gbps (full duplex) bandwidth per port Bullet 4 PXE network boot support Bullet 5 Fully compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab Bullets (Compact) Add two 10 Gigabit Ethernet ports (10Gbps) to a client, server or workstation through one PCI Express slot - Dual-port 10GbE network interface card w/ Intel X540 chip - PCIe 10G NIC w/ two 100/1000/10G RJ45 ports - 2-port PCI Express 10 Gigabit NIC Bullets (Consolidated) Add two 10 Gigabit Ethernet ports (10Gbps) to a client or server or workstation through one PCI Express slot - Dual-port 10GbE network interface card with Intel X540 Chip - PCIe 10G NIC with two 100/1000/10G RJ45 ports - 2-port PCI Express 10 Gigabit NIC/10gbase-T adapter card - 10Gb Ethernet server adapter with up to 20Gbps (full duplex) bandwidth per port - Fully compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab - Full or low-profile (LP bracket included) installation Marketing Copy Marketing Copy (No HTML) This 10Gbps PCI express network card lets you add two RJ45 ports through a single PCI Express slot, to deliver reliable high-speed network connections to your workstations and servers without draining your budget. Compatible with a broad range of operating systems, this versatile dual-port 10Gbps-t network interface card is ideal for many business applications that require upgrades to servers or workstations. Add two powerful 10-Gigabit Ethernet ports, with support for advanced features such as VLAN tagging, jumbo frames, and Auto-MDIX. This 2-port 10Gbps LAN card features the Intel X540 chipset. The X540 chipset provides many advanced features including Intel Virtualization Technology for connectivity and PXE network boot support. Compliant with IEEE 802.3/u/ab standards, the 2-port gigabit network card delivers a dependable way to upgrade or replace your existing network ports with dual 100/1000/10G compatible RJ45 ports. It connects through a single, four-lane (x8 or higher) PCI Express slot. With a dual-profile design, the RJ45 network card installs easily into a wide range of computer/server chassis, regardless of form factor. The 2 port converged network adapter comes equipped for installation in a full-sized chassis and includes a low-profile/half-height installation bracket that you can use as needed. The 10GBase-T NIC PCIE is backed by a StarTech.com 2-year warranty and free lifetime technical support. Applications - Upgrades to servers or workstations in need of enhanced performance, advanced features and greater reliability
- Upgrade a 10/100/1000 Ethernet port on your computer to 10GbE networking
- Ideal for high-demand database servers and mission-critical systems that need redundant network connectivity
- Add networking capabilities to an old system with no Ethernet port
Website Search Keyword - 10g Network Adapter
- network adapter card
- 2-Port PCIe 10G Ethernet Network Card
- 2-Port PCIe 10G Network Card
- 2-Port PCIe 10G Network Adapter Card
- 2-Port PCIe 10G NIC
- Dual-Port PCIe 10G Ethernet Network Card
- 2-Port NIC
- Dual-Port NIC
- 2 port network card
- Intel NIC
- 10gbase-t card
- 10gbase-t adapter
- 10G network card
- 10g network interface card
- 10g nic
- 10gbase-t nic
- pci express 10g nic
- pcie 10g network adapter
- intel 10g server adapter
- intel 10g nic
- 10 gigabit network card
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- UKCA - EMC/EMI - United Kingdom - UK Electromagnetic Compatibility Regulations 2016
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
- Recycling - Waste - Japan - Paper Recycling Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- Triman/Info-Tri - Packaging - Waste - European Union - Paper Box + paper tray/divider
- EU RIC + Italian Sorting - Packaging - Waste - European Union - Corrugated Fiberboard
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
Special Notes - Intel NIC Teaming is supported only on Windows Server OS (e.g., Server 2012, 2016) and not on desktop versions like Windows 10 or 11. System and Cable Requirements Available PCI Express x8 slot Accessory Products - C6ASPAT3BL
- C6ASPAT3GR
- C6ASPAT10BL
- C6ASPAT10GR
Related Products - ST2000SPEXI
- PEX1000SFP
- ST1000SPEX2
Constrained SKU Alternatives (Limited Stock) ST10GPEXNDPI Color Black Humidity 20~80% RH Operating Temperature 5°C to 50°C (41°F to 122°F) Product Length (mm) 163.000 Product Width (mm) 20.000 Product Height (mm) 120.000 Product Weight (g) 157.000 Storage Temperature -20°C to 60°C (-4°F to 140°F) TAA Compliant No Auto MDIX Yes Compatible Networks 10 Gbps/5G/2.5G/1G/100 Mbps Full Duplex Support Yes Jumbo Frame Support 9K max. Maximum Data Transfer Rate 20Gbps (full-duplex), 10Gbps (half-duplex) OS Compatibility - Windows 8
- Windows Server 2012
- Windows 10
- Windows 7
- Linux
- Windows Server 2016
- Windows Server 2019
- Windows 11
- Windows Server 2022
Promiscuous Mode Yes Supported Protocols IEEE 802.3ad (link aggregation), IEEE 802.1q (VLAN tagging) Bus Type PCI Express Card Type Standard Profile (LP bracket incl.) Chipset ID Intel - X540 Industry Standards Interface/Bridge RJ45 (10 Gigabit Ethernet) IO Card Port Style Integrated on Card LED Indicators - 2 - Link Speed
- 2 - Link Activity
Carton Depth (mm) 418 Carton Height (mm) 314 Carton Quantity 40 Carton Weight Gross (g) 10608 Included in Package - 1 - PCI Express 10GBase-T Ethernet card
- 1 - instruction manual
- 1 - low-profile bracket
Package Depth (mm) 145 Package Height (mm) 41 Package Width (mm) 209 Package Quantity 1 Package Weight (g) 234 Packaging Description 2 Port PCIe 10GBase-T Ethernet Network Card Packaging Description India 2 Port PCIe 10GBase-T Ethernet Network Card Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 PCI Express x8 Connector 1 (Quantity) 1 Connector 2 RJ-45 Connector 2 (Quantity) 2 Amazon Merchandising Manager Kathleen Marshall Artwork Due Date 2015-06-18 Buying Center - AV & Collaboration No Buying Center - End User Compute No Buying Center - Networking & Edge Yes Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,CL,CO,DE,DK,ES,EU,FR,HK,IE,IN,IT,JP,NL,NZ,PE,SE,SG,UK,US Primary Technology None Product Development Specialist Ray Aoki Product Information Creation Specialist (PICS) Alex Garcia Product Manager Rob Fleck Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Target Production Release 2015-07-24 Tech Lead Stefan Tirolese Technical Writer Andrew Richardson Technology Lifecycle None
