ST401P
Main Image
Product Name ********** Discontinued ************ Product Number ST401P UPC 065030772129 Lifecycle status Discontinued Warranty Lifetime Taxonomy Product > Legacy Discontinued Category Level 1 Legacy Category Category Level 2 Legacy Sub-Category Category Level 3 Legacy Group Product Title (Long) *D*Unidirectional 4-to-1 Parallel Autoswitch Bullet 1 Laser Printer Safe Bullet 2 Light and Compact Bullet 3 Adjustable "END OF FILE" time-out Bullet 4 LED "In-Service" indicator Bullet 5 Parallel switches are available in reversible models. Applications - Four (4) computers share one (1) printer
- Requires four (4) straight through DB25 male-to-male cables (SCxxMM) and one (1) parallel printer cable (PCxx, PBxx, PMCxx)
- AC power adapter (COMPACPOWER) is required only if the autoswitch cannot get enough power from devices or operates intermittently
TAA Compliant No General Specifications - Interface: Parallel
- Configuration: 4-1
- Power: Optional
- Timeout (seconds): 10 or 60
- Max. Length In: 15 ft., 4.6m
- Max. Length Out: 15 ft., 4.6m
- Out connectors: DB25 (Female)
- Dimensions (mm): 159 x 86 x 20
- Power: DC 9V 50mA (optional)
Carton Depth (mm) 0 Carton Height (mm) 0 Carton Weight Gross (g) 0 Included in Package - 1 - BI-TRONICS AUTO SWITCH
- 1 - USER'S MANUAL
- 1 - 3.5'' FLOPPY DRIVER DISK
Package Depth (mm) 0 Package Height (mm) 0 Package Width (mm) 0 Package Weight (g) 208.66 Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 en-US Content Approved Yes Product Manager Keith Rodrigues
