16 Port Star View KVM with OSD

Main Image

Product Name	16 Port Star View KVM with OSD
Product Number	SV1631DGB
UPC	065030800266
Warranty	3 Years
Taxonomy	Product > Legacy Discontinued
Country of Origin Europe & Japan	Taiwan
Country of Origin North America	Taiwan
Country of Origin History (1)	Taiwan
Country of Origin Revision (1)	1

Product Title (Long)	16 Port Star View KVM with OSD
Bullet 1	A dependable 3-year warranty provides peace of mind.
Bullet 2	Hot-pluggable to allow computers to be added or removed without worrying about having to reboot the other connected systems.
Bullet 3	"Keep-alive" feature draws power from PC keyboard ports if power is lost. Switch will continue to operate during power outage even it it loses power, retaining mouse control.
Bullet 4	Rugged, all-metal chassis for use in harsh environments and space-saving cabinets.
Bullet 5	Designed for guaranteed compatibility with Dell, Compaq, IBM and HP servers and systems.
Marketing Copy
Applications	Datacenter computer control Manufacturing line computer control PC test/burn-in computer control

Accessory Products	SVPS23N1_6 SVPS23N1_15 SVPS23N1_35 SVPS23N1_10 SVPS23N1_25 SVPS23N1_50 USB2PS2 GC56MF SVPOWER SVSERIALAD PS23N1THIN4 PS23N1THIN10 PS23N1THIN25 PS23N1THIN2 PS23N1THIN6 PS23N1THIN15 SV125
Related Products	SV1632DS SV832DS

Power Consumption (In Watts) 0.6W
Power Source AC Adapter Included
Color Black
Material Steel
Product Length (mm) 436
Product Width (mm) 220
TAA Compliant No

General Specifications	Ports: 16 PC ports (HDDB15 Male, 2x 6 Pin MiniDIN Female), 1 Console port (HDDB15 Female, 2x 6 Pin MiniDIN Female), 1 Feature Expansion port (8 pin MiniDIN Female) PC Selection methods: OSD Menu, Keyboard hot-key, Front panel button Video Bandwidth: 300 MHz Maximum resolution: 1920 x 1440 pixels @ 70Hz Enclosure: Metal, rackmount brackets included Dimensions: H3.5 x L17.2 x D8.7 inches (88 x 436 x 220mm) Weight: 8.26lbs (3.75kg) Power: 9V DC 600mA - Adapter included Certifications: FCC Part 15 Class A, CE Mark, VCCI
Maximum Analog Resolutions	1920 x 1440 @ 70 Hz
Maximum Number of Users	1
On-Screen Display	Yes

Power Consumption (In Watts)	0.6W
Power Source	AC Adapter Included
