SV1631DUTP
16 Port Cat 5 UTP KVM Switch
Control up to 16 VGA USB or PS/2 computers, connected using Cat 5 UTP cabling
Main Image
Product Images
Product Images
Product Name 16 Port Cat 5 UTP KVM Switch Product Number SV1631DUTP UPC 065030827621 Lifecycle status Discontinued Warranty 2 Years Taxonomy Product > Legacy Discontinued Category Level 1 Legacy Category Category Level 2 Legacy Sub-Category Category Level 3 Legacy Group Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) XXXXXX006X Product Title (Short) 16 Port USB PS/2 Cat5 UTP KVM Switch Product Title (Standard) StarTech.com 16 Port 1U Rackmount USB PS/2 Cat5 UTP KVM Switch - CAT5 UTP KVM switch - KVM switch - PS/2 - CAT5 - 16 ports - 1 local user - 1U - rack-mountable - stackable Product Title (Long) 16 Port 1U Rackmount USB PS/2 Cat5 UTP KVM Switch Title Ingram (Part 1) 16 Port 1U Rackmount USB PS/2 Ca Title Ingram (Part 2) t5 UTP KVM Switch Website Product Headline Control up to 16 VGA USB or PS/2 computers, connected using Cat 5 UTP cabling Bullet 1 A dependable 2-year warranty provides peace of mind Bullet 2 Auto-scan function automatically selects computer sequentially Bullet 3 Cascade configuration expands system capability up to 512 computers Bullet 4 Extends the distance between computers and switch - up to 130 feet for resolutions of 1280 x 1024 @ 60Hz, and 100 feet for a resolution of 1600 x 1200 @ 60Hz Bullet 5 Easy to use computer selection via port selection switches, Hotkeys and intuitive On Screen Display (OSD) menus Marketing Copy Applications - Enterprise network management
- Manufacturing line computer control
- PC test/burn-in computer control
- Server farms
Website Search Keyword - 16 Port
- CAT5
- SV1631DUTP
- Multiplatform
- KVM
- StarView
- UTP
- Enterprise
System and Cable Requirements - CAT5, CAT5e or CAT6 cable - 1 for each computer connected to the SV1631DUTP
- SV5PS2S - Connecting from SV1631DUTP to PS/2 computers
- SV5USBS - Connecting from SV1631DUTP to USB computers
Accessory Products - SV5USBS
- SV5PS2S
- SV125
- SV565UTP
- SC6MF
- SC10MF
- M45PATCH3BL
- M45PATCH6BL
- M45PATCH10BL
- SV5PS2S4P
- SV5PS2S8P
- SV5USBS4P
- SV5USBS8P
Related Products - SV831DUTP
- SV1115IPEXT
- RACKCONS1501
- RACKCONS1701
- RACKCONS1901
- SV1641HDIE
Equivalent Part Number in the UK SV1631DUTGB Power Source AC Adapter Included Center Tip Polarity Positive Color Black Material Steel Operating Temperature 0C~50C Product Length (mm) 437 Product Width (mm) 160.1 Product Height (mm) 44 Product Weight (g) 2700 Storage Temperature -20C~60C(0-80% Humidity) TAA Compliant No Hot-Key Selection No KVM IP Control No Maximum Analog Resolutions 1600x1200@ 60Hz(100 ft), 1280 x1024@ 60 Hz ( 130 ft) Maximum Cable Length (mm) 39635 Maximum Number of Users 1 Audio No Cables Included No Cascadable Yes Number of KVM Ports 16 Number of Monitors Supported 1 PC Video Type VGA Rack-Mountable Yes Supported Platforms USB and PS/2 Carton Depth (mm) 570 Carton Height (mm) 260 Carton Quantity 3 Carton Weight Gross (g) 10680 Included in Package - 1 - StarView 16 Port CAT5 KVM Switch
- 1 - Firmware upgrade cable
- 1 - Mounting brackets
- 1 - User manual
- 1 - Power adapter
Package Depth (mm) 123 Package Height (mm) 240 Package Width (mm) 550 Package Weight (g) 3160 Packaging Description 16 Port 1U VGA USB or PS/2 Cat5 UTP KVM Switch Packaging Description India 16 Port 1U VGA USB or PS/2 Cat5 UTP KVM Switch Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 RJ-45 Connector 1 (Quantity) 16 en-US Content Approved Yes Product Manager Daryl Hunt
