Main Image
SV1632DSGB
Main Image
Product Name 2 Console Shared Access 16 Port Starview KVM Switch Product Number SV1632DSGB UPC 065030800303 Warranty 3 Years Taxonomy Product > Legacy Discontinued Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) 1 Product Title (Long) 2 Console Shared Access 16 Port Starview KVM Switch Bullet 1 2 user consoles provides 2 points of access to the computers connected to the KVM switch. KVM control is shared between the consoles on a first come-first served basis. Only user 1 console can be active at a time. Bullet 2 On-Screen PC selection menu for fast and easy computer access Bullet 3 Compact 2U rack height takes up very little cabinet or rack space Bullet 4 Completely hot-pluggable feature allows you to add or remove keyboards, mice, monitors and even cascaded switches without powering down the switch or an attached computer Bullet 5 A front panel pushbutton and status lights for each port make PC selection and switch status monitoring fast and easy Marketing Copy Applications - Datacenter computer control
- Cabinets with 2U Rack Dense Servers
- Manufacturing computer control
- PC test/burn-in computer control
Accessory Products - SVPS23N1_6
- SVPS23N1_10
- SVPS23N1_15
- SVPS23N1_25
- SVPS23N1_35
- SVPS23N1_50
- SV560UTPGB
- USB2PS2
- GC56MF
- SVSERIALAD
- SVPOWER
- PS23N1THIN2
- PS23N1THIN6
- PS23N1THIN15
- SV125
Related Products - SV1631DGB
- SV832DSGB
Power Consumption (In Watts) 0.6W Power Source AC Adapter Included Material Steel Product Length (mm) 436 TAA Compliant No General Specifications - Ports: 16 PC ports (HDDB15 Male, 2x 6 Pin MiniDIN Female), 2 Console ports (HDDB15 Female, 2x 6 Pin MiniDIN Female), 1 Feature Expansion port (8 pin MiniDIN Female)
- PC Selection methods: OSD Menu, Keyboard hot-key, Front panel button
- Video Bandwidth: 200 MHz
- Maximum resolution: 1600 x 1280 pixels
- Enclosure: Metal, rackmount brackets included
- Dimensions:
- Weight:
- Power: 9V DC 600mA - Adapter included
- Certifications: FCC Part 15 Class A, CE Mark, VCCI
KVM IP Control No Maximum Analog Resolutions 1920 x 1440 Maximum Number of Users 1 On-Screen Display Yes Audio No Number of KVM Ports 16 Number of Monitors Supported 1 PC Video Type VGA Rack-Mountable Yes Supported Platforms PS/2 U Height 2U Connector 1 S-Video (Y/C) Connector 1 (Quantity) 1 Connector 2 PS/2 Connector 2 (Quantity) 36 Connector 3 VGA Connector 3 (Quantity) 18 en-US Content Approved Yes
