SV1641HDI
Main Image
Product Name 16 Port StarView IP Enterprise Hybrid KVM switch Product Number SV1641HDI UPC 065030804257 Lifecycle status Discontinued Warranty 2 Years Taxonomy Product > Legacy Discontinued Category Level 1 Legacy Category Category Level 2 Legacy Sub-Category Category Level 3 Legacy Group Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Product Title (Long) 16 Port USB + PS/2 Digital KVM Switch with OSD Bullet 1 Supports PCs with USB or PS/2 keyboard and mouse connectors Bullet 2 Universal KVM switch controls up to 16 computers directly and up to 136 computers by cascading 8 additional KVM switches Bullet 3 Compact 1U rack height takes up very little cabinet or rack space Bullet 4 Hot-pluggable feature allow computers to be added or removed without shutting down Bullet 5 Works with PC, Mac, Linux, and Sun Systems Marketing Copy Applications - Datacenter computer control
- Manufacturing line computer control
- PC test/burn-in computer control
- Co-location/ISP computer control
- Server farms
- BIOS level remote access to servers at co-location facilities and ISPs
- Enables access to existing KVM switches via TCP/IP
- Remote access for outsourced server / IT hardware management
- Remote access to mission-critical corporate datacenter servers
Accessory Products - RPORT
- PCM815SHNA
Input Current 0.6A Input Voltage 110V-240V AC Output Current 1.5A Output Voltage (V) 12V DC Power Source AC Adapter Included Plug Type M Center Tip Polarity Positive Color Black Material Steel Product Length (mm) 219 Product Width (mm) 406 Product Height (mm) 44.5 TAA Compliant No DVI Support No General Specifications KVM IP Control Yes Maximum Analog Resolutions 1920 x 1440 pixels local console Maximum Digital Resolutions 1600 x 1200 @ 85Hz Maximum Number of Users 1 active user plus up to 3 viewing Port Selection Support Hotkeys and OSD (On Screen Display) Audio No Cascadable Yes Number of KVM Ports 16 Number of Monitors Supported 1 PC Video Type VGA Rack-Mountable Yes Supported Platforms USB and PS/2 U Height 1U Carton Depth (mm) 650 Carton Height (mm) 290 Carton Quantity 3 Carton Weight Gross (g) 15030 Package Depth (mm) 119 Package Height (mm) 360 Package Width (mm) 508 Package Weight (g) 4610 Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 RJ-45 Connector 1 (Quantity) 1 Connector 2 DB-9 Serial Connector 2 (Quantity) 1 Connector 3 S-Video (Y/C) Connector 3 (Quantity) 1 Connector 4 VGA Connector 4 (Quantity) 1 Connector 5 PS/2 Connector 5 (Quantity) 2 Host Connector 1 VGA Host Connector 1 (Quantity) 16 en-US Content Approved Yes Product Manager Daryl Hunt
