SV221DVIDD
Main Image
Product Images
Product Images
BOM Image
Product Name 2 Port StarView DVI KVM Switch with Dual Display Product Number SV221DVIDD UPC 065030805513 Lifecycle status Discontinued Warranty 2 Years Taxonomy Product > Legacy Discontinued Category Level 1 Legacy Category Category Level 2 Legacy Sub-Category Category Level 3 Legacy Group Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX083X Product Title (Short) 2 Port DVI Dual Monitor KVM Switch Product Title (Standard) 2 Port DVI Dual Monitor KVM Switch with PS/2 -Dual Display SV221DVIDD - KVM switch - PS/2 - 2 ports - 1 local user Product Title (Long) 2 Port DVI Dual Monitor KVM Switch with PS/2 Title Ingram (Part 1) 2 Port DVI Dual Monitor KVM Swit Title Ingram (Part 2) ch with PS/2 Bullet 1 DVI-I interface technology supports both digital and analog video signal transmission Bullet 2 Switches instantly between two PCs Bullet 3 Rear connections provide a neat and secure environment Bullet 4 Supports PS/2 keyboards and mouse including M/S IntelliMouse, Explorer and Logitech NetMouse Bullet 5 Keyboard and mouse are hot pluggable, eliminating the need to reboot your systems Marketing Copy Applications - Designed for Dual DVI monitor enabled PCs
- Ideal for environments using desktops, workstations and servers with Flat Panel LCD monitors
Website Search Keyword - dual view
- dual display
- dual kvm
- multi-monitor
- multi monitor
- multi-display
- multi display
Accessory Products - DVIDDMM10
- DVIDDMM15
- DVIDDMM6
- DVIDDMM20
- DVIISMM10
- DVIISMM15
- DVIISMM6
- KXT102MM
- KXT102MM_25
Related Products SV421DVIDD Output Current 0.5A Output Voltage (V) 9V DC Power Consumption (In Watts) 0.5W Power Source Not Included (not required for standard applications) Color Black Material Steel Operating Temperature 0°C to 40°C (32°F to 104°F) Product Width (mm) 140 Product Depth (mm) 86 Product Height (mm) 62 Product Weight (g) 520 TAA Compliant No DVI Support Yes Hot-Key Selection Yes KVM IP Control No Maximum Analog Resolutions 1920x1440 (not intended for use with Widescreen displays) Maximum Digital Resolutions 1280x1024 Maximum Number of Users 1 OS Compatibility OS Independent Port Selection Support Push Button and Hotkeys Audio No Cables Included No Cascadable No LED Indicators 1 - Port Status (Numerical display) Number of KVM Ports 2 Number of Monitors Supported 2 PC Video Type DVI Rack-Mountable No Supported Platforms PS/2 Carton Depth (mm) 426 Carton Height (mm) 337 Carton Quantity 10 Carton Weight Gross (g) 9900 Included in Package - 1 - 2 Port KVM Switch
- 1 - Instruction Manual
Package Depth (mm) 40 Package Height (mm) 146 Package Width (mm) 233 Package Weight (g) 870 Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 DVI-I Dual-Link (29-Pin) Connector 1 (Quantity) 2 Connector 2 PS/2 Connector 2 (Quantity) 2 Host Connector 1 DVI-I Dual-Link (29-Pin) Host Connector 1 (Quantity) 4 Host Connector 2 PS/2 Host Connector 2 (Quantity) 4 en-US Content Approved Yes Product Manager Daryl Hunt
