SV231QDPU34K
2 Port Quad Monitor DP 4K 60Hz KVM Switch
KVM with USB | Quad Monitor | TAA Compliant | USB 3.0 Hub | DisplayPort 1.2 | Digital & Analog Audio
Main Image
Product Images
Product Images
Product Images
Product Images
Product Images
Product Images
Product Images
Quick-Start Guide
Product Name 2 Port Quad Monitor DP 4K 60Hz KVM Switch Product Number SV231QDPU34K UPC 065030881777 Lifecycle status Active Warranty 2 Years Taxonomy Product > KVMs, Switches & Splitters > Desktop KVMs Category Level 1 KVM Switches Category Level 2 Desktop KVMs Category Level 3 USB 3.0 - DisplayPort KVMs Family Pro Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) XXXXXX066X Product Title (Ultra-Short) 2 Pt DP KVM Switch Product Title (Short) 2-Pt Quad Monitor DisplayPort KVM Switch Product Title (Medium) 2 Port Quad Monitor DisplayPort KVM Switch Product Title (Standard) 2 Port Quad Monitor DisplayPort KVM Switch, 4K 60Hz UHD HDR, DP 1.2, 2 Port USB 3.0 Hub, 4x USB HID, Audio, Hotkey, TAA Product Title (Long) 2 Port Quad Monitor DisplayPort KVM Switch - 4K 60Hz UHD HDR - Desktop 4K DP 1.2 KVM with 2 Port USB 3.0 Hub (5Gbps) & 4x USB 2.0 HID Ports, Audio - Hotkey Switching - TAA Product Title (AMZ) 2 Port Quad Monitor DisplayPort KVM Switch - 4K 60Hz UHD HDR - Desktop 4K DP 1.2 KVM with 2 Port USB 3.0 Hub (5Gbps) & 4x USB 2.0 HID Ports, Audio - Hotkey Switching - TAA (SV231QDPU34K) Title Ingram (Part 1) 2 Pt DP KVM Switch Title Ingram (Part 2) 4K 60Hz Ultra HD Website Product Headline KVM with USB | Quad Monitor | TAA Compliant | USB 3.0 Hub | DisplayPort 1.2 | Digital & Analog Audio Bullet 1 IMPROVE EFFICIENCY: Switch between two computers with four monitors using USB and DisplayPort video from a single keyboard, monitor, and mouse using keyboard hotkeys or push buttons to switch between active computers Bullet 2 QUADRUPLE 4K 60Hz UHD: DisplayPort quad screen KVM switch supports up to 4K at 60Hz on four monitors for applications like CAD/CAM, video editing and content creation; works with major brands including Dell, HP, and Lenovo Bullet 3 TECH SPECS: 2 Port KVM | Quad Display | DisplayPort 1.2 | 3840 x 2160 60 Hz | HDCP 2.2 | HDR Support | 2 Port USB 3.0 Hub | 4x USB HID | Hotkey & Push Button | OS Independent | Stereo Analog + Digital Audio | DP + USB Console Bullet 4 USER-FRIENDLY: KVM switch with compact & durable steel housing features large buttons & easily accessible front-mounted integrated USB 3.0 port 5Gbps (USB 3.1/3.2 Gen 1) for sharing USB devices between connected computers Bullet 5 THE STARTECH.COM ADVANTAGE: This KVM is TAA compliant, and StarTech.com offers a 2-year warranty and free lifetime 24/5 multilingual technical support based in North America Bullets (Compact) 2 Port Quad Monitor DisplayPort KVM Switch with 2 Port USB 3.0 Hub 5Gbps - Hotkey/push button - Quad UHD 4K 60Hz HDR10 DP 1.2 (3840x2160) - HDCP 2.2 - Front facing USB 3.0 Port, 4x USB HID - 2 or 7.1ch Audio - OS Independent - 2 Year Warranty - TAA Bullets (Consolidated) 2 Port DisplayPort KVM switch with Quad display; Hotkey/manual switching - Access 2 systems with Quad 4K 60Hz DP video and USB 3.0 Hub from 1 console - works with brands like HP/Dell/Lenovo - Suited for video editing, CAD/CAM, content - 2 Port DP 1.2 | 3840x2160 60Hz | 4K 60Hz HDR10 | 2x USB 3.0 Hub | 4x USB HID | HDCP 2.2 | 2ch + 7.1ch Audio | OS Independent - Durable Steel Keyboard Video Mouse Switch with Front-mount USB port (USB 3.2/3.1 Gen 1) - TAA | StarTech.com 2-year warranty Marketing Copy Marketing Copy (No HTML) Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- CE - Safety - Electrical - European Union - Low Voltage Directive (LVD) 2014/35/EU
- Recycling - Waste - Japan - Plastic Recycling Mark
- Recycling - Waste - Japan - Paper Recycling Mark
- Triman/Info-Tri - Product - Waste - European Union - EEE Device + accessories + cords
Accessory Products - DP14MM1M
- DP14MM2M
- DP14MM3M
- USB3CAB1M
- USB3CAB2M
- USB3SAB10BK
- USB31CB1M
- USB315CB2M
- USB2CB3M
- DP2VGA3X5
- DP2DVIS
- DP2HDMI2
- DP2HDMI
- DP2HD4KS
- DISPLPORT6L10PK
Related Products - SV211DPUA4K
- SV231DPU34K
- SV431DPU3A2
- SV231TDPU34K
- SV431DD2DU3A
- SV431DL2DU3A
- SV231DHU34K6
- SV231HU34K6
- SV431HU34K6
Constrained SKU Alternatives (Limited Stock) SV231TDPU34K Input Current 1.0A Input Voltage 100 - 240 AC Output Current 3A Output Voltage (V) 12V DC Power Consumption (In Watts) 36W Power Source AC Adapter Included Plug Type M Center Tip Polarity Positive Color Black Humidity 0%~80% Material Steel Operating Temperature 0℃~40℃ Product Length (mm) 160.000 Product Width (mm) 100.000 Product Height (mm) 92.000 Product Weight (g) 994.000 Storage Temperature -10℃~60℃ TAA Compliant Yes Audio Specifications - DisplayPort - 5.1 Channel Audio
- DisplayPort - 2 Channel Audio
- Analog Stereo - 2 Channel Audio
Auto Scan 3, 8, 15 & 30 seconds Hot-Key Selection Yes KVM IP Control No MTBF (hours) 156 000 hrs On-Screen Display No OS Compatibility OS Independent Port Selection Support Push Button and Hotkeys Wide Screen Supported Yes Audio Yes Cables Included No CAC Support No Cascadable No Chipset ID Genesys Logic - GL3523 LED Indicators - 2 - Green (Power/Sync)
- 2 - Red (Selected Host)
Number of KVM Ports 2 Number of Monitors Supported 4 PC Video Type DisplayPort Supported Platforms USB 3.2 Gen 1 (5Gbps) Carton Depth (mm) 398 Carton Height (mm) 291 Carton Quantity 6 Carton Weight Gross (g) 10074 Included in Package - 1 - KVM Switch
- 1 - Universal Power Adapter (NA/JP, EU, UK, NZ)
- 4 - Rubber Feet
- 1 - Quick-Start Guide
Package Depth (mm) 187 Package Height (mm) 102 Package Width (mm) 253 Package Quantity 1 Package Weight (g) 1556 Packaging Description 2-Port Quad Monitor KVM Switch - DP - 4K 60Hz Packaging Description India 2-Port Quad Monitor KVM Switch - DP - 4K 60Hz Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 DisplayPort Connector 1 (Quantity) 4 Connector 2 USB-A (5Gbps, 4.5W) Connector 2 (Quantity) 2 Connector 3 USB-A (1.5Mbps, 2.5W) Connector 3 (Quantity) 4 Connector 4 3.5mm (3 Conductors, TRS) Connector 4 (Quantity) 1 Host Connector 1 DisplayPort Host Connector 1 (Quantity) 8 Host Connector 2 USB-B (480Mbps, 2.5W) Host Connector 2 (Quantity) 2 Host Connector 3 3.5mm (3 Conductors, TRS) Host Connector 3 (Quantity) 2 Actual Inbox Documents Created QSG in the box Amazon Merchandising Manager Kathleen Marshall Artwork Due Date 2020-09-10 Buying Center - AV & Collaboration Yes Buying Center - Data Center No Buying Center - End User Compute Yes Buying Center - Networking & Edge Yes Digital Content Due Date 2021-06-17 Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level - 2 Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,CL,DE,DK,ES,FI,FR,IE,IT,JP,NL,NZ,PL,SE,SG,UK,US Primary Technology None Product Development Specialist Otto Gutierrez Product Information Creation Specialist (PICS) Dan Dagenais Product Manager Rob Fleck Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Target Development Completion Date 2020-08-12 Target Production Release 2020-09-10 Tech Lead Stefan Tirolese Technical Writer Dan Dagenais Technology Lifecycle Latest Vending Machine Not Compatible with Vending Machine
