SV431DDUSGB
4 Port DVI/VGA USB KVM Switch
Share a keyboard and mouse as well as 1 VGA and 1 DVI displays/monitors between four multimedia computers
Main Image
Product Images
Product Images
Product Name 4 Port DVI/VGA USB KVM Switch Product Number SV431DDUSGB UPC 065030831901 Lifecycle status Discontinued Warranty 2 Years Taxonomy Product > Legacy Discontinued Category Level 1 Legacy Category Category Level 2 Legacy Sub-Category Category Level 3 Legacy Group Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX083X Product Title (Short) 4 Port 2 Display DVI VGA USB KVM Switch Product Title (Standard) StarTech.com 4 Port Dual Display DVI VGA USB KVM Switch with Audio Product Title (Long) 4 Port Dual Display DVI VGA USB KVM Switch with Audio Title Ingram (Part 1) 4 Port Dual Display DVI VGA USB Title Ingram (Part 2) KVM Switch with Audio Website Product Headline Share a keyboard and mouse as well as 1 VGA and 1 DVI displays/monitors between four multimedia computers Bullet 1 Direct channel selection and operation using front-panel push button and keyboard hotkeys Bullet 2 DVI-I Single Link interface technology supports digital and analog video signal transmission Bullet 3 HDCP compliant for digital contents protection Bullet 4 Metal enclosure for best shielding and protection Bullet 5 Status LED display for easy port status monitoring Marketing Copy Applications - Great solution for environments using desktops, workstations and servers where both VGA and DVI digital are required
- Ideal for financial/banking industries, graphic designers, engineers, multi-media designers, and industries using CAD/CAM applications, where high resolution dual display units are needed
- Ideal for multimedia computer systems supporting Dual Head video cards
- Suitable for use in environments with electromagnetic interference and wherever a sturdy protective metal case is needed
Website Search Keyword - KVM Switch
- KVM
- 4 Port
- USB DVI VGA
- Dual Display
- Audio
- audio
- dual view
- dual display
- dvi vga kvm
- dual kvm
- multi-monitor
- multi monitor
- multi-display
- multi display
Accessory Products - DVIIDMM10
- MXT101MMHQ10
- USB2HAB10
- USB2HAB15
- USB2HAB6
- USBDVI4N1A10
- USBDVI4N1A15
- USBDVI4N1A6
- USBVGA4N1A10
- USBVGA4N1A6
Related Products - SV221DVIDD
- SV231DVIDDU
- SV231UADVI
- SV231USBA
- SV421DVIDD
- SV431DDUSB
- SV431DVIDDU
- SV431DVIUA
- SV431UADVI
Output Current 1.7A Output Voltage (V) 9V DC Power Source AC Adapter Included Center Tip Polarity Positive Color Black Material Steel Product Width (mm) 253 Product Depth (mm) 100 Product Height (mm) 66 Product Weight (g) 1150 TAA Compliant No DVI Support Yes - Single Link Hot-Key Selection No KVM IP Control No Maximum Analog Resolutions 2048x1536 Maximum Digital Resolutions 1920x1200 Maximum Number of Users 1 OS Compatibility OS Independent Audio Yes Cables Included No Cascadable No Number of KVM Ports 4 Number of Monitors Supported 2 PC Video Type DVI+VGA Rack-Mountable No Supported Platforms USB Carton Depth (mm) 552 Carton Height (mm) 225 Carton Quantity 6 Carton Weight Gross (g) 11280 Included in Package - 1 - Instruction Manual
- 1 - Power Adapter
- 1 - 4 port DVI VGA KVM Switch
- 1 - Software CD
Package Depth (mm) 162 Package Height (mm) 194 Package Width (mm) 268 Package Weight (g) 1680 Packaging Description 4 Port DVI VGA Dual Monitor USB KVM Switch Packaging Description India 4 Port DVI VGA Dual Monitor USB KVM Switch Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 USB-A (480Mbps, 2.5W) Connector 1 (Quantity) 2 Connector 2 VGA Connector 2 (Quantity) 1 Connector 3 DVI-I Dual-Link (29-Pin) Connector 3 (Quantity) 1 Connector 4 USB-A (480Mbps, 2.5W) Connector 4 (Quantity) 2 Connector 5 3.5mm (3 Conductors, TRS) Connector 5 (Quantity) 2 Host Connector 1 VGA Host Connector 1 (Quantity) 4 Host Connector 2 DVI-I Dual-Link (29-Pin) Host Connector 2 (Quantity) 4 Host Connector 3 USB-B (480Mbps, 2.5W) Host Connector 3 (Quantity) 4 Host Connector 4 3.5mm (3 Conductors, TRS) Host Connector 4 (Quantity) 8 en-US Content Approved Yes Product Manager Daryl Hunt
