SV431DLU3A
4Port Dual Link KVM Switch w/ USB 3 Hub & Cables
Control 4 Dual Link DVI, USB 3.0 equipped PCs with a single monitor, keyboard, mouse and audio peripheral set
Main Image
Product Images
Product Name 4Port Dual Link KVM Switch w/ USB 3 Hub & Cables Product Number SV431DLU3A UPC 065030854467 Lifecycle status Discontinued Warranty 2 Years Taxonomy Product > Legacy Discontinued Category Level 1 Legacy Category Category Level 2 Legacy Sub-Category Category Level 3 Legacy Group Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX083X Product Title (Ultra-Short) 4Pt USB3 DVI KVM Swt Product Title (Short) 4 Port USB 3.0 Dual Link DVI KVM Switch Product Title (Standard) 4 Port SuperSpeed USB 3.0 Dual Link DVI KVM Switch with Audio and Cables Product Title (Long) 4 Port SuperSpeed USB 3.0 Dual Link DVI KVM Switch with Audio and Cables Product Title (AMZ) 4 Port SuperSpeed USB 3.0 Dual Link DVI KVM Switch with Audio and Cables - USB 3 KVM Switch - USB KVM with Audio - 2560x1600 (SV431DLU3A) Title Ingram (Part 1) 4Port USB 3 Dual Link DVI KVM Title Ingram (Part 2) Switch with USB 3.0 Hub & Cables Website Product Headline Control 4 Dual Link DVI, USB 3.0 equipped PCs with a single monitor, keyboard, mouse and audio peripheral set Bullet 1 Integrated USB 3.0 (5 Gbps) hub Bullet 2 Hot-key and front-panel push buttons for easy computer selection Bullet 3 Video, audio and USB cables included Bullet 4 USB keyboard and mouse console connections Bullet 5 Supports resolutions up to 2560x1600 Marketing Copy Applications - Ideal for financial/banking industries, graphic designers, multi-media applications and industries using CAD/CAM applications
- Integrated USB 3.0 hub and Mic/Audio allows the user to have full multimedia control of two computers and share USB peripherals in a home or office
- Control four DVI USB computers with a single set of console peripherals (Keyboard, Mouse, and Monitor)
Required Regulatory Compliance Marks FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference Accessory Products - USB3SAB10
- USB3SAB10BK
- MU10MMS
- DVIDDMM10
- SVA9M2NEUA
Related Products - SV231HDU3A
- SV231U3A
- SV231DLU3A
- SV431DPU3A
- SV431HDU3A
- SV431U3A
- SV231DPU3A
Input Current 0.5 A Input Voltage 100 - 240 AC Output Current 2 A Output Voltage (V) 9V DC Power Source AC Adapter Included Plug Type M Center Tip Polarity Positive Color Black Humidity 0~90% RH Non-Condensing Material Steel Operating Temperature 0°C to 40°C (32°F to 104°F) Product Length (mm) 255 Product Width (mm) 102 Product Height (mm) 45 Product Weight (g) 950 Storage Temperature -20°C to 60°C (4°F to 140°F) TAA Compliant No Hot-Key Selection Yes KVM IP Control No Maximum Cable Length (mm) 10000 Maximum Digital Resolutions 2560 x 1600 MTBF (hours) 94,650 Hours OS Compatibility OS Independent Port Selection Support Push Button and Hotkeys Audio Yes Cables Included Yes Cascadable No LED Indicators - 4 - PC Selection Indicator
- 4 - Hub selection indicator
Number of KVM Ports 4 Number of Monitors Supported 1 PC Video Type DVI Rack-Mountable No Supported Platforms USB 3.2 Gen 1 (5Gbps) Carton Depth (mm) 500 Carton Height (mm) 213 Carton Quantity 6 Carton Weight Gross (g) 20965 Included in Package - 1 - 4 Port USB 3.0 KVM Switch
- 4 - DVI-D M/M Cables
- 4 - USB 3.0 A-B Cables
- 4 - 3.5mm Audio/Mic Cables
- 1 - Universal Power Adapter (NA/UK/EU)
- 1 - Instruction Manual
Package Depth (mm) 160 Package Height (mm) 191 Package Width (mm) 270 Package Quantity 1 Package Weight (g) 3252 Packaging Description 4 Port Dual Link DVI KVM w/ USB 3.0, Audio, Cables Packaging Description India 4 Port Dual Link DVI KVM w/ USB 3.0, Audio, Cables Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 USB-A (5Gbps, 4.5W) Connector 1 (Quantity) 2 Connector 2 DVI-I Dual-Link (29-Pin) Connector 2 (Quantity) 1 Connector 3 USB-A (480Mbps, 2.5W) Connector 3 (Quantity) 2 Connector 4 3.5mm (3 Conductors, TRS) Connector 4 (Quantity) 2 Host Connector 1 DVI-I Dual-Link (29-Pin) Host Connector 1 (Quantity) 4 Host Connector 2 USB-B (5Gbps, 4.5W) Host Connector 2 (Quantity) 4 Host Connector 3 3.5mm (3 Conductors, TRS) Host Connector 3 (Quantity) 8 Amazon Merchandising Manager Kathleen Marshall Artwork Due Date 2013-10-07 en-US Content Approved Yes Graphic Designer Shane Arnett Launch Markets (concatenated) CA,EU,UK,US Primary Technology None Product Development Specialist Scott Dunlop Product Information Creation Specialist (PICS) Dan Dagenais Product Manager Tim North Product Photographer Alejandra Valencia Tech Lead Stefan Tirolese Technical Writer Andrew Richardson Technology Lifecycle Legacy Vending Machine Not Compatible with Vending Machine
