SV4X8E
Main Image
Product Name *D* Matrix StarView KVM Switch - 4 users control 8 PCs Product Number SV4X8E UPC 065030790444 Warranty 3 Years Taxonomy Product > Legacy Discontinued Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) 1 Product Title (Long) *D* Matrix StarView KVM Switch - 4 users control 8 PCs Bullet 1 (4) user console ports Bullet 2 (8) computer connection ports Bullet 3 OSD On-Screen Display allows computers to be named and selected from a pop-up menu for convenient PC selection Bullet 4 Emulates keyboard and mouse on non-selected ports for error-free bootup Bullet 5 Each user can enter their own names for the connected PCs Marketing Copy Applications - A busy server room where more than 1 person needs access to the connected servers simulateously
- A help desk where all the internal systems are set up and shared by up to 4 personnel
- A monitoring system for manufacturing, security, or system testing where there are more than 1 user
Accessory Products SV560UTP Material Steel Product Width (mm) 180 TAA Compliant No General Specifications - LEDs: Active, CPU Number
- Buttons: Reset
- Power: AC 110/220V internal switching power suppply
- Dimensions (LxWxH): 16.9x7.1x3.5" (430x180x89mm)
Maximum Analog Resolutions 1600 x 1280 @ 60 Hz Maximum Number of Users 4 On-Screen Display Yes Included in Package - 1 - 4 User to 8 PC Matrix StarView with OSD
- 1 - Cable
Connector 1 DB-25 Parallel / Serial Connector 1 (Quantity) 8 Connector 2 DB-25 Parallel / Serial Connector 2 (Quantity) 4 en-US Content Approved Yes
