SV565USAGB
Cat5 USB Serial Audio KVM Console Extender
Extend VGA video, USB, audio and serial signals up to 300m (1000ft) over Cat 5 or better cabling
Main Image
Product Images
Product Images
Product Name Cat5 USB Serial Audio KVM Console Extender Product Number SV565USAGB UPC 065030840576 Lifecycle status Discontinued Warranty 2 Years Taxonomy Product > Legacy Discontinued Category Level 1 KVM Switches Category Level 2 KVM Extenders Category Level 3 VGA KVM Extenders Country of Origin Europe & Japan Canada Country of Origin North America Canada Product Title (Short) KVM Console Extender w/ Serial Over Cat5 Product Title (Standard) USB VGA KVM Console Extender w/ Serial & Audio Product Title (Long) USB VGA KVM Console Extender w/ Serial & Audio Over Cat5 UTP - 1000 ft Product Title (AMZ) USB VGA KVM Konsolen Extender mit Seriell und Audio über Cat5 UTP - bis zu 300m (SV565USAGB) Title Ingram (Part 1) USB VGA KVM Console Extender w/ Title Ingram (Part 2) Serial & Audio Over Cat5 UTP Website Product Headline Extend VGA video, USB, audio and serial signals up to 300m (1000ft) over Cat 5 or better cabling Bullet 1 Automatic image calibration and adjustment Bullet 2 High resolution support up to 1920x1080 @60Hz Bullet 3 Manual configuration via serial interface Bullet 4 Maximum supported distance of 1000ft (300m) Bullet 5 Integrated wall mounting brackets on remote unit Marketing Copy Applications - Extend USB keyboard and mouse, RS232 serial, VGA, and audio up to 1000ft away
- Monitor computer-controlled equipment in a factory or warehouse
- Remotely control secure servers
- Use one or more servers in a server room from a remote location
- Perfect for adding console controls for areas not environmentally suitable for a full PC or server
- Can act as a thin client for power users controlling powerful rack mounted servers as their desktop machines
- Full serial support for remote applications such as touchscreens, barcode scanners, etc.
- Ideal for high security environments where the server and data contained within a server room, while the user has no direct access to the hardware
Website Search Keyword - Console Extender
- dumb terminal
- KVM Extender
- Port Extender
- rack server desktop console
- Remote Console
- remote kiosk
- Remote Server
- secure pc
- Server Extender
- thin client
- USB Extender
- USB KVM
- VGA Audio Serial Extender
Required Regulatory Compliance Marks - WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
Special Notes Supports most combo keyboard and mouse sets (including Wireless) Accessory Products - M45PATCH6BL
- M45PATCH10BL
- M45PATCH15BL
- MXT101MMHQ
- MXT101MMHQ10
- MXT101MMHQ3
- USB2HAB6
- USB2HAB10
Related Products - PS2UTPEXT
- SV565UTPEU
- SV565UTPUEU
Input Voltage 100 - 240 AC Output Voltage (V) 5 DC Power Source AC Adapter Included Plug Type N Center Tip Polarity Positive Color Black Humidity 80% RH Material Aluminum Operating Temperature 0°C to 40°C (32°F to 104°F) Product Length (mm) 0.000 Product Width (mm) 156.000 Product Depth (mm) 112 Product Height (mm) 26.000 Product Weight (g) 250.000 Storage Temperature -40°C to 70°C (-40°F to 158°F) TAA Compliant Yes KVM IP Control No Maximum Analog Resolutions 1920x1080 @ 60Hz Max Transfer Distance 300m [984ft] OS Compatibility OS Independent Audio Yes Cascadable Yes LED Indicators - 0 - Power LED (Receiver and Transmitter)
- 0 - RJ45 Link LED (Local and Remote)
- 0 - Setup LED (Local)
- 0 - USB Link (Keyboard and Mouse on Local, Single USB on Remote)
Number of KVM Ports 1 Number of Monitors Supported 1 PC Video Type VGA Rack-Mountable No Supported Platforms USB Carton Depth (mm) 595 Carton Height (mm) 394 Carton Quantity 14 Carton Weight Gross (g) 20940 Included in Package - 1 - Instruction Manual
- 1 - Local Unit
- 1 - Power Adapter
- 1 - Remote Unit
- 1 - USB Cable
- 1 - VGA cable
- 3 - Power Cords (NA/UK/EU)
Package Depth (mm) 91 Package Height (mm) 165 Package Width (mm) 300 Package Quantity 1 Package Weight (g) 1410 Packaging Description USB VGA KVM Console Extender Over Cat5 - 300m Packaging Description India USB VGA KVM Console Extender Over Cat5 - 300m Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 3.5mm (3 Conductors, TRS) Connector 1 (Quantity) 1 Connector 2 VGA Connector 2 (Quantity) 1 Connector 3 3.5mm (3 Conductors, TRS) Connector 3 (Quantity) 2 Connector 4 DB-9 Serial Connector 4 (Quantity) 1 Connector 5 VGA Connector 5 (Quantity) 1 Connector 6 RJ-45 Connector 6 (Quantity) 2 Connector 7 USB-A (480Mbps, 2.5W) Connector 7 (Quantity) 2 Host Connector 1 3.5mm (3 Conductors, TRS) Host Connector 1 (Quantity) 2 Host Connector 2 DB-9 Serial Host Connector 2 (Quantity) 1 Host Connector 3 VGA Host Connector 3 (Quantity) 1 Host Connector 4 RJ-45 Host Connector 4 (Quantity) 1 Host Connector 5 USB-B (480Mbps, 2.5W) Host Connector 5 (Quantity) 1 Amazon Merchandising Manager Kathleen Marshall Artwork Due Date 2014-06-18 Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Graphic Designer Shane Arnett Launch Markets (concatenated) EU,UK Primary Technology None Product Development Specialist Scott Dunlop Product Information Creation Specialist (PICS) Dan Dagenais Product Manager Rob Fleck Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Tech Lead Stefan Tirolese Technical Writer Andrew Richardson Technology Lifecycle Legacy Vending Machine Not Compatible with Vending Machine
