Main Image
SV565UTPGB
USB-PS2 UTP KVM Console Extender
Operate a PS/2 & VGA KVM or PC up to 500ft away as if it were right in front of you
Main Image
Product Images
Product Images
Product Images
BOM Image
Product Name USB-PS2 UTP KVM Console Extender Product Number SV565UTPGB UPC 065030816113 Lifecycle status Discontinued Warranty 2 Years Taxonomy Product > Legacy Discontinued Category Level 1 KVM Switches Category Level 2 KVM Extenders Category Level 3 VGA KVM Extenders Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) XXXXXX066X Product Title (Short) PS2 KVM Console Cat5 Extender Product Title (Standard) StarTech.com PS/2 KVM Console Extender - cat5 extender - external - up to 150 m Product Title (Long) PS2 KVM Console Extender Cat5 Extender - 500 ft Title Ingram (Part 1) PS2 KVM Console Extender Cat Title Ingram (Part 2) 5 Extender - 500 ft Website Product Headline Operate a PS/2 & VGA KVM or PC up to 500ft away as if it were right in front of you Bullet 1 Can be used with a single computer or connected to an existing KVM switch Bullet 2 Supports auto-switching between host and remote users or dedicated control Bullet 3 PS/2-based computers are supported at the host and remote locations Bullet 4 Easy installation using industry-standard UTP network cable Bullet 5 Intuitive hotkey commands Marketing Copy Applications - Use one or more servers in a server room from a remote location
- Monitor computer-controlled equipment in a factory or warehouse
Required Regulatory Compliance Marks - ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
Special Notes Product weights, measurements and connectors indicate a single unit only (either Host or Remote) Accessory Products - SVECON2
- SVECON4
- SVECON6
- SVECON10
- SVECON15
- SVECON25
- SVECON50
- SVECONUS6
- SVECONUS10
- SVECONUS15
- SVA9M2NEUA
Related Products SV565UTPUGB Input Current 0.2 A Input Voltage 100 - 240 AC Output Current 0.6 A Output Voltage (V) 9V DC Power Consumption (In Watts) 5.4 Power Source AC Adapter Included Plug Type M Center Tip Polarity Positive Color Black Humidity 0~80% RH Operating Temperature 0°C to 40°C (32°F to 104°F) Product Length (mm) 75 Product Width (mm) 155 Product Height (mm) 20 Product Weight (g) 299 Storage Temperature -20°C to 60°C (-4°F to 140°F) TAA Compliant Yes KVM IP Control No Max Transfer Distance 150m [492ft] OS Compatibility OS Independent Supported Resolutions Audio No Number of KVM Ports 2 Number of Monitors Supported 1 PC Video Type VGA Rack-Mountable No Supported Platforms PS/2 Carton Depth (mm) 510 Carton Height (mm) 295 Carton Quantity 6 Carton Weight Gross (g) 10800 Included in Package - 1 - Local Unit
- 1 - Remote Unit
- 2 - Power Adapters
- 2 - Packs, Rubber Feet
- 1 - Instruction Manual
Package Depth (mm) 85 Package Height (mm) 243 Package Width (mm) 294 Package Quantity 1 Package Weight (g) 1600 Packaging Description USB PS/2 VGA KVM Console Extender - 500ft Packaging Description India USB PS/2 VGA KVM Console Extender - 500ft Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 RJ-45 Connector 1 (Quantity) 1 Connector 2 VGA Connector 2 (Quantity) 1 Connector 3 PS/2 Connector 3 (Quantity) 2 Host Connector 1 VGA Host Connector 1 (Quantity) 1 Amazon Merchandising Manager Kathleen Marshall Artwork Due Date 2014-06-18 Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Graphic Designer Shane Arnett Launch Markets (concatenated) UK Primary Technology None Product Development Specialist Scott Dunlop Product Information Creation Specialist (PICS) Dan Dagenais Product Manager Rob Fleck Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Tech Lead Stefan Tirolese Technical Writer Andrew Richardson Technology Lifecycle Legacy Vending Machine Not Compatible with Vending Machine
