TB32HD2
Thunderbolt 3 dual HDMI Video Adapter
Use a Thunderbolt 3 port on your Windows system to run resource demanding applications on two UHD 4K displays
Main Image
Product Images
Product Images
Product Images
Product Images
Product Images
BOM Image
Video Link YouTube
Video Link YouTube
Product Name Thunderbolt 3 dual HDMI Video Adapter Product Number TB32HD2 UPC 065030864053 Lifecycle status Discontinued Warranty 2 Years Taxonomy Product > Legacy Discontinued Category Level 1 Display and Video Adapters Category Level 2 Thunderbolt 3 Display Adapters Category Level 3 Thunderbolt 3 to HDMI Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX031X Product Title (Ultra-Short) Thunderbolt to HDMI Product Title (Short) Thunderbolt 3 to Dual HDMI Adapter - 4K Product Title (Medium) Thunderbolt 3 to Dual Monitor HDMI Adapter - Thunderbolt to 2x HDMI - 4K 30Hz Product Title (Standard) Thunderbolt 3 to Dual HDMI Adapter – 4K 30Hz – Windows Only Compatible – Thunderbolt 3 to HDMI – USB-C to HDMI Product Title (Long) Thunderbolt 3 to Dual HDMI Adapter - 4k 30Hz - Windows only Compatible Product Title (AMZ) Thunderbolt 3 to Dual HDMI Display Adapter - 4K 30Hz - Certified TB3 to HDMI Monitor Adapter - Compatible w/ Windows Only (TB32HD2) Title Ingram (Part 1) Thunderbolt 3 to Dual HDMI - Title Ingram (Part 2) Thunderbolt to HDMI - 4K 30Hz Website Product Headline Use a Thunderbolt 3 port on your Windows system to run resource demanding applications on two UHD 4K displays Bullet 1 Connect two UHD 4K displays to your computer through a single Thunderbolt 3 port Bullet 2 Run resource demanding applications on 4K displays at 30 Hz without draining system resources Bullet 3 Thunderbolt Certified Bullet 4 No external power adapter required Bullet 5 Backward compatible with lower resolutions like high-definition 1920x1200 and 1080p Bullets (Compact) Windows only not Mac Compatible - Run the most resource demanding applications on two Ultra HD 4K displays from a single Thunderbolt 3 port - 4K 30 Hz - Works with Lenovo P70, Dell XPS & Precision - USB Type-C with Thunderbolt 3 to 2x HDMI Bullets (Consolidated) Windows only not Mac Compatible - Run the most resource demanding applications on two Ultra HD 4K displays from a single Thunderbolt 3 port - Works with Thunderbolt 3 devices like Elitebook X2 1012 G1 Dell XPS 13 (9350) and Zbook 15 G3 and 17 G3 - works with HDMI televisions monitors and projectors - Dual display resolutions up to 4K at 30 Hz - Thunderbolt to HDMI/USB Type-C with Thunderbolt 3 to dual HDMI/USB C with Thunderbolt 3 to Dual HDMI Marketing Copy Marketing Copy (No HTML) Applications - Connect your computer to two 4K monitors
- Design high-resolution, graphic-intensive content, such as CAD drawings and Photoshop graphic images
- Create and Edit 4K video while using resource intensive software
- Multitask by previewing your raw output content on a second 4K display
- Connect to different systems with 4K or 1080p displays for hot desking in BYOD office applications
- Use one screen for reference data such as websites, while composing 4K content on your other screen
- Span a spreadsheet or worksheet across multiple displays to avoid side-scrolling
- Access panoramic views that are built into software applications, while viewing helpful tutorial content on your laptop monitor
- Connect your Dell XPS or Dell Precision to two external DP monitors
Website Search Keyword - usb type-c to thunderbolt
- Thunderbolt to HDMI
- Lenovo P70
- Lenovo P50
- USB C to HDMI
- USB Type C to HDMI
- Thunderbolt 3 to HDMI
- thunderbolt 3
- thunderbolt
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
Accessory Products - HDMM1
- HDMM3
- HDMM6
- HDMM8
- HDMM10
- HDMM12
- HDMM15
- HDMM20
- HDDVIMM3
- HDMIDVIMM6
- HDMIDVIMM10
- HDMIDVIMM15
- HDMIDVIMM20
Related Products - TB32DP2
- TB32DP2T
- MSTCDP122HD
- MSTCDP123DP
- MSTCDP122DP
Cable Length (mm) 254 Color Silver Material Aluminum Product Length (mm) 353 Product Width (mm) 60 Product Height (mm) 16 Product Weight (g) 102 TAA Compliant No Maximum Data Transfer Rate 20 Gbps Maximum Digital Resolutions 4K @ 30 Hz Maximum Supported Resolution 4K 30Hz (3840x2160) OS Compatibility - Windows 10
- Windows 8
- Windows 11
- Windows 11 ARM
Supported Resolutions USB Type and Rate Thunderbolt 3 (40Gbps) Video Output Port HDMI Active or Passive Adapter Active Audio Yes AV Input Thunderbolt™ 3 USB-C (24-pin) (40Gbps) AV Output HDMI Chipset ID - Alpine Ridge
- Parade 181HDMA1
- PD TI TPS65982
Converter Type Adapters Number of Displays 2 Carton Depth (mm) 420 Carton Height (mm) 320 Carton Quantity 40 Carton Weight Gross (g) 21008 Included in Package 1 - Thunderbolt 3 to dual HDMI adapter Package Depth (mm) 145 Package Height (mm) 40 Package Width (mm) 210 Package Quantity 1 Package Weight (g) 220 Packaging Description Thunderbolt™ 3 to Dual HDMI Adapter - 4k 30Hz Packaging Description India Thunderbolt™ 3 to Dual HDMI Adapter - 4k 30Hz Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 USB-C (Thunderbolt 40Gbps) Connector 1 (Quantity) 1 Connector 2 HDMI Connector 2 (Quantity) 2 Amazon Merchandising Manager Kristian Haighton Artwork Due Date 2016-02-26 Buying Center - AV & Collaboration No Buying Center - End User Compute Yes Buying Center - Networking & Edge No Enhanced Gallery Designer Rob Selenis en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,DE,DK,ES,FR,IE,IT,JP,NL,NZ,SE,SG,UK,US Primary Technology Thunderbolt 3 Product Development Specialist Abhinav Pathak Product Information Creation Specialist (PICS) Dan Dagenais Product Manager David Muzinic Product Performance Specialist John Mardinly Product Photographer Caleigh Le Grand Target Production Release 2016-04-22 Tech Lead Brian Linseman Technical Writer Andrew Richardson Technology Lifecycle None
