TB33A1C
Thunderbolt 3 to USB 3 1 3 x A and 1 x C
High Speed USB Hub | 4x Dedicated Independent Ports | 3x USB-A 1x USB-C
Main Image
Product Images
Product Images
Product Images
Product Name Thunderbolt 3 to USB 3 1 3 x A and 1 x C Product Number TB33A1C UPC 065030871204 Lifecycle status End of Life Warranty 2 Years Taxonomy Product > Other > Unclassifiables Category Level 1 Computer Cards and Adapters Category Level 2 Components, Tools and Accessories Category Level 3 Expansion Slot Conversion and Extension Family Thunderbolt 3 Hubs Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX031X Product Title (Ultra-Short) Thunderbolt 3 Hub Product Title (Short) Thunderbolt 3 to USB 3.1 Host Controller Product Title (Medium) Thunderbolt 3 USB 3.2 Multi-Channel Hub Controller - 4 Port 10G / 5G - 3xA 1xC Product Title (Standard) External Thunderbolt 3 to USB Controller - 3 Host Chips - 1 Each for 5Gbps Ports, 1 Shared on 10Gbps Ports - Self Powered Product Title (Long) External Thunderbolt 3 to USB Controller - 3 Dedicated USB Host Chips - 1 Each for 5Gbps USB-A Ports, 1 Shared Between 10Gbps USB-C & USB-A Ports - TB3 Daisy Chain - Self Power Product Title (AMZ) External Thunderbolt 3 to USB Controller - 3 Dedicated USB Host Chips - 1 Each for (5Gbps) USB-A Ports, 1 Shared Between 10Gbps USB-C & USB-A Ports - TB3 Daisy Chain- Self Power (TB33A1C) Title Ingram (Part 1) Thunderbolt 3 to USB 3.1 Multi- Title Ingram (Part 2) Channel Hub Controller, 4 Pt 10G/5G Website Product Headline High Speed USB Hub | 4x Dedicated Independent Ports | 3x USB-A 1x USB-C Bullet 1 MAXIMIZED BANDWIDTH: Utilize TB3 to drive 3 dedicated USB controllers over 4x PCIe lanes for high-performance USB transfer speeds; One controller for each 5Gbps port; 10Gbps ports share a controller Bullet 2 HIGH PERFORMANCE USB PORTS: Thunderbolt 3 certified controller w/ 2x USB-A 5Gbps USB 3.2 Gen 1 (USB 3.2 Gen 1), 1x USB-A & 1x USB-C at 10Gbps SuperSpeed (Gen 2); Front BC 1.2 Fast Charge port up to 7.5W Bullet 3 FAST TRANSFER SPEEDS: SSDs, NVMe drives, VR Headsets & 3D scanners need full USB throughput for optimal performance, multi function dock w/multiple controllers provides dedicated bandwidth to devices Bullet 4 FLEXIBLE THUNDERBOLT 3 PORT: Downstream TB3 port w/ 3 modes of operation incl DP Alt Mode to connect 2nd monitor (5K 30Hz or 4K 60Hz) or daisy chain up to 5 TB3 devices, or connect a USB Type-C device Bullet 5 EASY SETUP: Auto-installation of drivers in supported OS; Adapter Hub has been tested & works with Windows 7 & up, MacOS 10.12 & up, and Linux; Incl 1.6" (0.5m) TB3 host cable & 65W universal PSU Bullets (Compact) 3 dedicated controllers: One for each USB 3.2 Gen 1 5Gbps port/2x 10Gbps ports share controller - 2x USB-A USB 3.2 Gen 1, 1xA & 1xC (Gen 2) - Flexible TB3 port w/DP Alt Mode/USB-C port/TB3 daisy chain - Fast Charge - 1.6ft cable - Win/MacOS - 65W PSU Bullets (Consolidated) 3 dedicated controllers over 4x PCIe lanes for high-performance USB transfer speeds | One controller for each 5Gbps port | 10Gbps ports share controller - Thunderbolt 3 to USB Controller w/ 2x USB-A 5Gbps USB 3.2 Gen 1 | 1x USB-A/1x USB-C at 10Gbps (Gen 2) | BC 1.2 Fast Charge port 7.5W - For SSDs/NVMe/VR headsets/3D scanners - Flexible TB3 port: DP Alt Mode for 2nd monitor 4K 60Hz/TB3 daisy chain/USB Type-C port - Hub auto installs on Win/MacOS | 1.6" TB3 cable | 65W PSU Marketing Copy Marketing Copy (No HTML) Applications - Connect multiple bus-powered SSDs with dedicated bandwidth for faster read/write access
- Connect a Thunderbolt 3 laptop to your USB devices such as printer, keyboard or mouse
- Maximize the performance of high-bandwidth devices such as 3D scanners with the independent dedicated ports
Website Search Keyword - usb hub
- USB Hubs
- usb 3.0 hub
- usb-c adapter
- USB-C hub
- usb-c hubs
- usb c dock
- USB 3 Hub
- usb-c to usb
- usb-c to usb-a
- 4 port usb hub
- usb multiport
- usb port hub
- usb 3.1 hub
- USB Type c hub
- thunderbolt 3 adapter
- thunderbolt 3 to usb adapter
- multi usb adapter
- thunderbolt 3 docking station
- usb type c to usb
- thunderbolt 3 hub
- multi port usb hub
- usb hub powered
- usb type c to type a
- usb port expander
- thunderbolt 3 to usb c adapter
- Type c hub
- thunderbolt 3 to usb 3.1
- usb multiport adapter
- usb c controller
- multiport adapter
- thunderbolt 3 controller
- usb c port hub
- usb c to c
- usb type c controller
- usb hub adapter
- usb c to usb a
- thunderbolt 3 to usb c
- usb type c to c
- thunderbolt 3 controller chip
- type c usb 3.1 hub
- usb 3 type c hub
- thunderbolt 3 to usb 3.1 adapter
- thunderbolt 3 to usb 3.1 hub
- usb c to usb a hub
- usb 3.0 type c hub
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
Special Notes - When connecting a display to the Thunderbolt 3 USB-C port, a USB-C video adapter might be required depending on the input of your display.
- Secondary Thunderbolt 3 port can also be used to connect USB 3.1 (10Gbps) USB-Type C devices, such as USB 3.1 Storage Enclosure or Hubs. Backwards compatible with USB 3.1 Gen 1 (USB 3.0), and USB 2.0.
- USB 3.1 Gen 1 is also known as USB 3.0; this connectivity standard offers speeds up to 5Gbps. USB 3.1 Gen 2 offers speeds up to 10Gbps.
System and Cable Requirements - Thunderbolt 3 equipped computer with a Thunderbolt 3 port.
- Your laptop's Thunderbolt 3 port must support USB Power Delivery 2.0 in order to power and charge your laptop.
Accessory Products - CDP2HD
- CDP2VGA
- CDP2DVI
- CDP2DP
- MSTCDP122DP
- ICUSBAUDIOB
- DKT30CHV
- USB3SDOCKDD
- USB3SDOCKHD
- DK30A2DH
- CDP2DPMM1MB
- CDP2DPMM6B
- CDP2HDMM1MB
- CDP2HDMM2MB
- MSTCDP122HD
- TB32HD24K60
- TB32DP2T
- TB32DP2
- TB32HD2
- MSTCDP123HD
Related Products - TB3DKDPMAW
- TB3DK2DPPD
- TB3DK2DPW
- TB31PCIEX16
- DKT30CHPD
- CDP2HDUACP
- DKT30CHPDW
- MST30C2HDPPD
- MST30C2DPPD
- DK30CH2DPPD
- HB30C3A1CFB
- HB30C3APD
- HB30C4AFPD
- HB30C3A1CFS
- HB30C3A1GE
- HB30C3A1CST
Input Current 1.8 A Input Voltage 100 - 240 AC Output Current 3.25 A Output Voltage (V) 20V DC Power Consumption (In Watts) 65W Power Delivery 15W Power Source AC Adapter Included Plug Type N Center Tip Polarity Positive Cable Length (mm) 500 Color Silver & Black Humidity 90% RH Material Aluminum Operating Temperature 0°C to 40°C (32°F to 104°F) Primary Material Aluminum Product Length (mm) 148.000 Product Width (mm) 74.000 Product Height (mm) 23.500 Product Weight (g) 200.000 Storage Temperature -20°C to 70°C (-4°F to 158°F) TAA Compliant No Maximum Data Transfer Rate Aggregate Bandwidth 20Gbit/s Maximum Digital Resolutions 3840 x 2160 (4K) 60Hz MTBF (hours) 1,936,146 hours OS Compatibility - Windows 7
- Windows 8
- Windows 10
- macOS High Sierra (10.13)
- macOS Mojave (10.14)
- macOS Catalina (10.15)
- macOS Big Sur (11.0)
- Windows 11
- macOS Monterey (12.0)
- macOS Ventura (13.0)
- macOS Sonoma (14.0)
- macOS Sequoia (15.0)
- macOS Tahoe (26.0)
UASP Support Yes USB Type and Rate USB 10Gbps Bus Type - Thunderbolt 3
- USB 3.2 Gen 2 10Gbps
- USB 3.2 Gen 1 (5 Gbps)
Chipset ID Industry Standards Laptop Dock / USB Hub Fast-Charge No USB-C Device Port(s) Yes USB-C Host Connection No USB Port Type USB-A, USB-C Carton Depth (mm) 310 Carton Height (mm) 374 Carton Quantity 6 Carton Weight Gross (g) 9940 Included in Package - 1 - Thunderbolt 3 controller
- 1 - Thunderbolt 3 Cable (50 cm)
- 1 - universal power adapter (NA/JP, UK, EU, ANZ)
- 1 - quick-start guide
Package Depth (mm) 189 Package Height (mm) 117 Package Width (mm) 288 Package Quantity 1 Package Weight (g) 1554 Packaging Description Thunderbolt 3 to USB 3.1 Controller - 1x USB-C, & 3x USB-A Packaging Description India Thunderbolt 3 to USB 3.1 Controller - 1x USB-C, & 3x USB-A Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 USB-C (Thunderbolt 40Gbps) Connector 1 (Quantity) 2 Connector 2 USB-A (5Gbps, 4.5W) Connector 2 (Quantity) 2 Connector 3 USB-A (10Gbps, 4.5W) Connector 3 (Quantity) 1 Connector 4 USB-C (10Gbps, 4.5W) Connector 4 (Quantity) 1 Amazon Merchandising Manager Veronica Ye Artwork Due Date 2017-07-04 Buying Center - AV & Collaboration No Buying Center - End User Compute Yes Buying Center - Networking & Edge Yes Digital Content Due Date 2017-11-17 Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,DE,DK,ES,EU,FI,FR,HK,IE,IT,JP,NL,NZ,SE,SG,UK,US Primary Technology Thunderbolt 3 Product Development Specialist Scott Dunlop Product Information Creation Specialist (PICS) Alex Garcia Product Manager Natalie Goodale Product Performance Specialist Aaron Bens Product Photographer Caleigh Le Grand Target Development Completion Date 2017-10-27 Target Production Release 2017-11-03 Tech Lead Brian Linseman Technical Writer Alex Garcia Technology Lifecycle None Vending Machine Not Compatible with Vending Machine
