US1GC301AUW
USB 3 0 Type C to Gigabit Ethernet Adapter with USB 3 0 Type
USB-C to Network Adapter | 10/100/1000Mbps | Thunderbolt™ 3 Compatible | RJ45
Main Image
Enhanced Images
Product Images
Product Images
Product Images
Video Link YouTube
Product Name USB 3 0 Type C to Gigabit Ethernet Adapter with USB 3 0 Type Product Number US1GC301AUW UPC 065030882941 Lifecycle status Active Warranty 2 Years Taxonomy Product > Cards & Adapters > Network Cards & Adapters Category Level 1 Networking Category Level 2 Laptop Network Adapters Category Level 3 USB-C Ethernet Adapters Family Classic Connect Ethernet+Hub Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX076X Country of Origin History (2) Malaysia Country of Origin Revision (2) XXXXXX156X Product Title (Ultra-Short) USB-C to Gigabit Product Title (Short) USB C Network Adapter - GbE w/USB A Port Product Title (Medium) USB-C Ethernet Adapter with Extra USB Port - USB 3.1 Type-C Gen 1 Product Title (Standard) USB C to Gigabit Ethernet Adapter with USB A Port - White 1Gbps NIC USB 3.0/3.1 Type C to RJ45 Port/LAN Network Adapter TB3 Product Title (Long) USB C to Gigabit Ethernet Adapter w/USB A Port - White 1Gbps NIC USB 3.0/USB 3.1 Type C Network Adapter - 1GbE USB-C RJ45/LAN TB3 Compatible Windows MacBook Pro Chromebook Product Title (AMZ) USB C to Gigabit Ethernet Adapter w/USB A Port - White 1Gbps NIC USB 3.0/USB 3.1 Type C Network Adapter - 1GbE USB-C RJ45/LAN TB3 Compatible Windows MacBook Pro Chromebook (US1GC301AUW) Title Ingram (Part 1) USB-C Ethernet Adapter - Title Ingram (Part 2) with Extra USB Port Website Product Headline USB-C to Network Adapter | 10/100/1000Mbps | Thunderbolt™ 3 Compatible | RJ45 Bullet 1 SECURE WIRED CONNECTIVITY: Portable USB C to Gigabit Ethernet Adapter allows you to connect to GbE Network from USB-C/Thunderbolt 3 Laptop incl. MacBook/MacBook Pro, Surface/Surface Book, & Chromebook Bullet 2 EXTRA USB 3.0/3.1 PORT: USB-C to Ethernet and USB Adapter adds a RJ45 Ethernet Port for wired LAN access and an additional open USB Type-A Port for connecting another peripheral device Bullet 3 USB-C or TB3 | 1x RJ45 | 1 x USB Type A Device Port | 1 Gbps Data Speed | 1000 / 100 / 10 Mbps Auto-Negotiation | Realtek RTL8153 | 9K Jumbo Frame | VLAN | WoL | Compact Design | USB Bus Powered Bullet 4 DRIVERLESS PLUG-AND-PLAY: Quick setup and compatibility with Windows XP/7/8.1/10/11, Windows Server 2016, Linux LTS Kernel 3.14+, MacOS 10.11 to 10.15, Chrome OS Bullet 5 THE STARTECH.COM ADVANTAGE: StarTech.com offers a 2-year warranty and free lifetime 24/5 multilingual technical support based in North America Bullets (Compact) USB C Gigabit Ethernet adapter securely connects to wired network (LAN) using RJ45 on USB C or Thunderbolt 3 device - White USB C NIC adds extra USB 3.1 Type-A Port - Realtek RTL8153 - Compact - Apple MacBook Pro/ Surface/Chromebook - 2 Yr Warranty Bullets (Consolidated) Compact USB-C to Gigabit Ethernet Adapter connects to a GbE Network from a USB 3.1 Type-C or TB3 Laptop - USB 3.0 NIC adds extra USB Type-A Port for a connecting peripheral device - USB-C or Thunderbolt 3 | 1x RJ45 | 1 x USB Type-A Port | 1 Gbps Data Speed | 10/100/1000 Mbps | Realtek RTL8153 |9K Jumbo Frame |VLAN |WoL |USB Powered - Driverless plug-and-play w/ Windows XP/7/ 8.1/10/11 Windows Server 2016 Linux LTS Kernel 3.14 MacOS 10.11 to 10.15 Chrome OS - StarTech.com 2-year warranty Marketing Copy Marketing Copy (No HTML) Applications - Add Gigabit Ethernet capabilities to your MacBook, Chromebook Pixel, Dell XPS 12 or Dell Latitude 12 7000 Series 2-in-1
- Turn your USB-C port into a Gigabit LAN RJ45 port
- Add an extra USB peripheral along with your network adapter
Website Search Keyword - USB 3.1
- USB-C
- USB C
- USB Type-C to ethernet
- USB type c
- USB NIC
- USB C NIC
- USB type-c
- USB C network adapter
- usb type c network adapter
- USB 3.1 Gen 1
- apple ethernet adapter
- belkin usb to lan converter
- ethernet adapter
- ethernet adapter with usb port
- ethernet dongle
- ethernet to usb c
- ethernet to usb c adapter
- gigabit ethernet adapter
- gigabit ethernet dongle
- mac ethernet adapter
- macbook lan adapter
- network adapter
- portable network adapter
- thunderbolt 3 ethernet adapter
- thunderbolt 3 network adapter
- thunderbolt 3 to ethernet
- thunderbolt 3 to ethernet adapter
- thunderbolt 3 to gigabit ethernet
- thunderbolt 3 to lan
- thunderbolt 3 to network adapter
- thunderbolt 3 to rj45
- thunderbolt 3 to usb converter
- thunderbolt to usb converter
- usb 3.0 to rj45 converter
- usb 3.1 ethernet adapter
- usb c ethernet adapter
- usb c network adapter
- usb c nic
- usb c to ethernet
- usb c to ethernet and usb
- usb c to ethernet cable
- usb c to gigabit ethernet adapter
- usb c to lan adapter
- usb c to lan converter
- usb c to network adapter
- usb c to rj45
- usb c to rj45 adapter
- usb c to usb 3.0 adapter
- usb c to usb 3.0 converter
- usb c to usb a
- usb c to usb adapter
- usb c to usb converter
- usb dongle to ethernet
- usb dongle to ethernet adapter
- usb Ethernet adapter
- usb ethernet dongle
- usb gigabit adapter
- usb lan adapter
- usb network adapter
- usb nic
- usb to ethernet
- usb to ethernet adapter
- usb to ethernet converter
- usb to gigabit ethernet converter
- usb to rj45
- usb type c ethernet adapter
- usb type c to ethernet
- usb type c to ethernet adapter
- usb type c to gigabit ethernet adapter
- usb type c to lan
- usb type c to rj45
- usb type c to usb 3.0 adapter
- usbc to ethernet
Required Regulatory Compliance Marks - Triman/Info-Tri - Product - Waste - European Union - EEE Device
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- UKCA - EMC/EMI - United Kingdom - UK Electromagnetic Compatibility Regulations 2016
- EU RIC + Italian Sorting - Packaging - Waste - European Union - Corrugated Fiberboard
- Triman/Info-Tri - Packaging - Waste - European Union - Paper Box + plastic bag + Paper/foam divider/tray
- Recycling - Waste - Japan - Paper Recycling Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
Accessory Products - N6PATCH3BK
- N6PATCH5BL
- N6PATCH5BK
- N6PATCH10BK
- N6PATCH15BL
- 45PATCH10BK
- 45PATCH3BK
- 45PATCH6BK
- RJ45PATCH15
Related Products - USB31000S
- US1GC30B
- US1GC30W
- US1GC301AU
Constrained SKU Alternatives (Limited Stock) USB31000SPTW Input Voltage 5V DC Output Voltage (V) 5 DC Power Source USB-Powered Cable Length (mm) 203 Color White Humidity 5% ~ 80% RH Material Plastic Network Adapter Form Factor Attached Cable Operating Temperature 0°C to 50°C (32°F to 122°F) Primary Material Plastic Product Length (mm) 275.000 Product Width (mm) 35.000 Product Height (mm) 17.000 Product Weight (g) 38.000 Storage Temperature -10°C to 60°C (14°F to 140°F) TAA Compliant No Auto MDIX Yes Compatible Networks 10/100/1000 Mbps Full Duplex Support Yes Jumbo Frame Support 9K max. Maximum Data Transfer Rate 5 Gbps (USB 3.1 Gen 1) OS Compatibility - Chrome OS
- Windows 8
- Windows 7
- macOS Sierra (10.12)
- Windows Server 2012
- Linux
- Mac OS X El Capitan (10.11)
- macOS Mojave (10.14)
- Windows 10
- macOS High Sierra (10.13)
- macOS Big Sur (11.0)
- Windows 11
- macOS Monterey (12.0)
- macOS Ventura (13.0)
- macOS Sonoma (14.0)
- Windows 11 ARM
- macOS Sequoia (15.0)
- macOS Tahoe (26.0)
Promiscuous Mode Yes USB Speed USB 3.2 Gen 1 (5Gbps) Wake-On-LAN (WOL) Yes Bus Type USB 3.2 Gen 1 Chipset ID Realtek RTL8153</br> VLI VL817 Industry Standards - IEEE 802.3i (10BASE-T)
- IEEE 802.3u (100BASE-T)
- IEEE 802.3ab (1000BASE-T)
- IEEE 802.1q (VLAN Tagging)
Interface/Bridge RJ45 (Gigabit Ethernet) LED Indicators - 1 - Green: 10/100 Link/Activity
- 1 - Amber: Gigabit Link/Activity
Network Adapter Host USB 3.0 - USB-C Network Adapter LAN Ports 1 USB Pass-Through Yes Carton Depth (mm) 322 Carton Height (mm) 364 Carton Quantity 80 Carton Weight Gross (g) 8156 Included in Package 1 - USB-C to GbE Network Adapter Included In Package for Label 1 - USB-C To Gbe Network Converter Package Depth (mm) 143 Package Height (mm) 31 Package Width (mm) 170 Package Quantity 1 Package Weight (g) 88 Packaging Description USB-C to GbE Adapter - USB 3.1 Gen 1 Packaging Description India USB-C to GbE Converter - USB 3.1 Gen 1 Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 USB-C (5Gbps, 4.5W) Connector 1 (Quantity) 1 Connector 2 USB-A (5Gbps, 4.5W) Connector 2 (Quantity) 1 Connector 3 RJ-45 Connector 3 (Quantity) 1 Amazon Merchandising Manager Kathleen Marshall Artwork Due Date 2019-08-01 Buying Center - AV & Collaboration No Buying Center - Data Center No Buying Center - End User Compute Yes Buying Center - Networking & Edge Yes Digital Content Due Date 2019-09-06 Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,CL,CO,DE,DK,ES,EU,FI,FR,HK,IE,IN,IT,JP,MX,NL,NZ,PE,SE,UK,US Primary Technology USB-C Priority New Product N/A Product Development Specialist Ray Aoki Product Information Creation Specialist (PICS) Alex Garcia Product Manager Rob Fleck Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Target Development Completion Date 2019-08-02 Target Production Release 2019-08-22 Tech Lead Stefan Tirolese Technical Writer Evan Hanbidge Technology Lifecycle Mainstream
