US1GC303APD
USB-C to GbE Converter with 3-Port Hub - PD Charging
Connect to a GbE network plus add three USB Type-A ports and PD Charging through your laptop’s USB-C port
Main Image
Product Images
Product Images
Product Images
Product Images
Product Name USB-C to GbE Converter with 3-Port Hub - PD Charging Product Number US1GC303APD UPC 065030869973 Lifecycle status Active Warranty 2 Years Taxonomy Product > Cards & Adapters > Network Cards & Adapters Category Level 1 Networking Category Level 2 Laptop Network Adapters Category Level 3 USB-C Ethernet Adapters Family Classic Connect Ethernet+Hub+PD Country of Origin Europe & Japan Vietnam Country of Origin North America Vietnam Country of Origin History (1) China Country of Origin Revision (1) XXXXXX012X Country of Origin History (2) Vietnam Country of Origin Revision (2) XXXXXX190X Product Title (Ultra-Short) USBC GbE Adapter/Hub Product Title (Short) Adapter Hub USB C to Ethernet 3 Port Product Title (Medium) USB-C to Ethernet Adapter with 3-Port USB 3.0 Hub and Power Delivery Product Title (Standard) USB-C to Ethernet Adapter with 3-Port USB 3.0 Hub and Power Delivery - USB-C GbE Network Adapter + USB Hub w/ 3 USB-A Ports Product Title (Long) USB-C to Ethernet Adapter with 3-Port USB 3.0 Hub and Power Delivery Product Title (AMZ) USB C to Ethernet Adapter – 3 Port – with Power Delivery (USB PD) – Power Pass Through Charging – USB C Adapter (US1GC303APD) Title Ingram (Part 1) USB-C to Ethernet Adapter with Title Ingram (Part 2) 3-Port USB 3.0 Hub - Power Delivery Website Product Headline Connect to a GbE network plus add three USB Type-A ports and PD Charging through your laptop’s USB-C port Bullet 1 Add powerful connectivity to your USB-C enabled device, with a GbE RJ45 port and three USB Type-A ports Bullet 2 Supports USB Power Delivery 2.0 to power and charge your laptop and network adapter, when using your laptop’s USB-C based power adapter Bullet 3 Portable travel-sized network adapter and hub, ideal for mobile use Bullet 4 Supports USB 3.0 (5Gbps) Bullet 5 Integrated cable with reversible USB-C connector, which is Thunderbolt 3 data port compatible Bullets (Compact) Connect to a GbE network and add 3 USB Type-A ports & PD Charging through your laptop’s USB-C port - USB-C to Ethernet Adapter w/ 3-Port USB 3.0 Hub & Power Delivery - Ideal for MacBook Pro, Dell XPS 13 & other USB-C laptops - USB-C GbE Adapter + hub Bullets (Consolidated) Connect to a GbE network plus add three USB Type-A ports and PD Charging through your laptop’s USB-C port - USB-C to Ethernet Adapter with 3-Port USB 3.0 Hub and Power Delivery - USBC GbE Network Adapter + USB 3.0 Hub - Ideal for any USB-C laptop that uses a USB-C power adapter incl MacBook Pro/MacBook Air/Dell XPS 13 and HP Spectre x360 - Supports USB Power Delivery 2.0 when using your laptops USB C power adapter - Travel-sized and self-powered ideal for mobile use/MacBook USB adapter Marketing Copy Marketing Copy (No HTML) Applications - Ideal for mobile professionals who require wired network connections and USB peripheral connectivity in one convenient adapter
- Charge your laptop and your network adapter at the same time, using your laptop’s USB-C power adapter
Website Search Keyword - USB-C to Ethernet Adapter
- USB-C to GbE Adapter
- USB-C Network Adapter
- USB-C Network Adapter with 3-Port USB 3.0 Hub
- 3-Port USB 3.0 Hub
- USB 3.0 Hub
- USB Hub
- USB-C Gigabit Ethernet Adapter
- USB-C GbE Adapter
- USB-C GbE network Adapter
- network adapter
- U460-003-3AGALC
- U460-003-3AGB-C
Required Regulatory Compliance Marks - Triman/Info-Tri - Product - Waste - European Union - EEE Device + accessories
- EU RIC + Italian Sorting - Packaging - Waste - European Union - Corrugated Fiberboard
- Triman/Info-Tri - Packaging - Waste - European Union - Paper Box + plastic bag + Paper/foam divider/tray
- Recycling - Waste - Japan - Paper Recycling Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- UKCA - EMC/EMI - United Kingdom - UK Electromagnetic Compatibility Regulations 2016
Special Notes - The adapter's USB-C port is for USB Power Delivery only. It does not support DisplayPort alt mode, or data transfers.
- Not all USB-C ports support the full functionality of the USB Type-C standard. Ensure that your host laptop's USB-C port supports USB Power Delivery 2.0
- The adapter can connect to a host laptop’s USB-C port that doesn’t support USB Power Delivery 2.0. However, in this configuration if a power adapter is connected to the hub, it will not pass power through to your host laptop.
- USB 3.0 is also known as USB 3.1 Gen 1; this connectivity standard offers speeds up to 5Gbps.
System and Cable Requirements - Available USB Type-C port - USB 3.0 (5Gbps) (to ensure the network adapter powers and charges your laptop, your host laptop's USB-C port must support USB Power Delivery 2.0)
- Optional: USB-C power adapter (for example, your laptop’s USB-C based power adapter)
Related Products US1GC30PD Input Voltage 5V DC Output Voltage (V) 5 DC Power Delivery 60W Power Source USB-Powered Cable Length (mm) 150 Color Black Humidity 10~90% RH (Non-condensing) Material Plastic Network Adapter Form Factor Attached Cable Operating Temperature 0°C to 45°C (32°F to 113°F) Primary Material Plastic Product Length (mm) 95.000 Product Width (mm) 41.000 Product Height (mm) 17.000 Product Weight (g) 46.000 Storage Temperature -10°C to 70°C (14°F to 158°F) TAA Compliant No Auto MDIX Yes Auto-Negotiation Yes Compatible Networks 10/100/1000 Mbps Flow Control Full duplex flow control Full Duplex Support Yes Jumbo Frame Support 9K max. Maximum Data Transfer Rate OS Compatibility - Chrome OS
- Windows 8
- Windows 7
- macOS Sierra (10.12)
- Windows Server 2012
- Windows Server 2016
- Linux
- Mac OS X El Capitan (10.11)
- Windows 10
- macOS High Sierra (10.13)
- macOS Mojave (10.14)
- Windows Server 2019
- macOS Catalina (10.15)
- macOS Big Sur (11.0)
- Windows 11
- macOS Monterey (12.0)
- macOS Ventura (13.0)
- Windows Server 2022
- macOS Sonoma (14.0)
- Windows 11 ARM
- macOS Sequoia (15.0)
- macOS Tahoe (26.0)
- Windows Server 2025
UASP Support Yes USB Type and Rate USB 3.0 (5Gbps) Bus Type USB 3.2 Gen 1 (5Gbps) Chipset ID Industry Standards - USB 3.0 - Backward compatible with USB 2.0 and 1.1
- IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
- IEEE 802.3az Energy-Efficient Ethernet, IEEE 802.3x Flow Control, 802.1q VLAN Tagging, 802.1p Layer 2 Priority Encoding
Interface/Bridge - USB 3.2 Gen 1 (5Gbps)
- RJ45 (Gigabit Ethernet)
Laptop Dock / USB Hub Fast-Charge No Network Adapter Host USB 3.0 - USB-C Network Adapter LAN Ports 1 USB-C Device Port(s) USB Power Delivery USB-C Host Connection Yes Carton Depth (mm) 338 Carton Height (mm) 324 Carton Quantity 60 Carton Weight Gross (g) 7660 Included in Package - 1 - USB hub
- 1 - quick-start guide
Included In Package for Label - 1 - USB hub
- 1 - quick-start guide
Package Depth (mm) 143 Package Height (mm) 33 Package Width (mm) 173 Package Quantity 1 Package Weight (g) 104 Packaging Description USB-C to GbE Adapter with 3-Port Hub - PD Charging Packaging Description India USB-C to GbE Converter with 3-Port Hub - PD Charging Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 USB-A (5Gbps, 4.5W) Connector 1 (Quantity) 3 Connector 2 RJ-45 Connector 2 (Quantity) 1 Connector 3 USB-C (5Gbps, 4.5W) Connector 3 (Quantity) 1 Connector 4 USB-C (100W PD Only) Connector 4 (Quantity) 1 Amazon Merchandising Manager Kathleen Marshall Artwork Due Date 2017-01-27 Buying Center - AV & Collaboration No Buying Center - Data Center No Buying Center - End User Compute Yes Buying Center - Networking & Edge Yes Digital Content Due Date 2017-03-17 Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,CL,CO,DE,DK,ES,EU,FR,HK,IE,IT,JP,MX,NL,NZ,PE,SE,SG,UK,US Primary Technology USB-C Product Development Specialist Ray Aoki Product Information Creation Specialist (PICS) Alex Garcia Product Manager Rob Fleck Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Target Development Completion Date 2017-01-27 Target Production Release 2017-02-03 Tech Lead Stefan Tirolese Technical Writer Andrew Richardson Technology Lifecycle Mainstream
