USB2004EXT2
Extender over Cat5 or Cat6 4 Port USB Extender
Extend four USB 2.0 connections up to 330ft away from the computer over Cat5 or Cat6 cable
Main Image
Product Images
Product Images
Quick-Start Guide
Product Name Extender over Cat5 or Cat6 4 Port USB Extender Product Number USB2004EXT2 UPC 065030841559 Lifecycle status Discontinued Warranty 2 Years Taxonomy Product > Legacy Discontinued Category Level 1 Computer Cards and Adapters Category Level 2 USB Cards and Extenders Category Level 3 USB Extenders - USB 2.0 Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX040X Product Title (Short) 4 Port USB 2.0 Extender over Cat5/Cat6 Product Title (Standard) USB Over Ethernet Extender - 4 Port - Cat5 or Cat6 - Up to 330' - USB Over CAT5 Extender Product Title (Long) 4-Port USB Extender - Up to 330 ft (100m) USB 2.0 over Cat5/Cat6 Extender - 480 Mbps USB Over Ethernet Extender Product Title (AMZ) 4-Port USB Extender - Up to 330 ft (100m) USB 2.0 over Cat5/Cat6 Extender - 480 Mbps USB Over Ethernet Extender (USB2004EXT2) Title Ingram (Part 1) 4 Port USB 2.0 Extender over Cat Title Ingram (Part 2) 5 or Cat6 - Up to 330 ft Website Product Headline Extend four USB 2.0 connections up to 330ft away from the computer over Cat5 or Cat6 cable Bullet 1 500mA of power per port Bullet 2 High Speed USB 2.0 compliant with data transfer rates up to 480 Mbps Bullet 3 Maximum extension distance of up to 100m / 330 ft over Cat5 cabling Bullet 4 No driver or software required Bullet 5 Plug-and-Play and hot-swap compatible Bullets (Compact) Extend four USB 2.0 connections up to 330ft away from your computer using Cat5 or Cat6 cable - Extends your USB devices up to 100 m (330 ft) over a single Cat5 cable - Includes surface mounting brackets for both units - OS independent & hassle-free Bullets (Consolidated) NEW MODEL NOW AVAILABLE: USB2004EXT2NA; Extend four USB 2.0 connections up to 330ft away from the computer over Cat5 or Cat6 cable - USB 2.0 to CAT5 extender - USB 2.0 over CAT 5 Extender - USB 2.0 Ethernet Extender - USB 2.0 Extender - Extend up to four USB 2.0 devices up to 100 m / 330 ft over a single Cat5 cable - Includes surface mounting brackets for both units Marketing Copy Marketing Copy (No HTML) The 4-port USB 2.0 extender lets you extend USB 2.0 devices over Cat 5 or better Ethernet cable at distances of up to 330ft (100m). An included power adapter at remote end provides up to 500 mA of power per port, letting you access and power up to four USB 2.0 devices at remote locations away from the host computer system. This USB 2.0 over Cat5/Cat6 extender provides support for data transfer rates of up to 480 Mbps, is Plug-and-Play and hot-swap compatible and is also backwards compatible with USB 1.x devices. This versatile USB over LAN extension hub offers a fast, easy, and flexible solution for business or industrial applications with durable metal housing, and an included surface-mounting bracket kit. The USB over ethernet transmitter receiver is backed by a Startech.com 2-year warranty and free lifetime technical support. Applications - Industrial control environments where the host computer must be located away from interference or contamination
- Reduce cable clutter and the need for mid-point USB hubs/repeaters by running a single, easy-to-install Cat5/Cat6 cable
- Secured environments where the host computer must be in a secure, inaccessible location from the keyboard, mouse, camera or other USB input devices
- Use existing in-wall Cat5/Cat6 wiring to extend USB connections between rooms
Website Search Keyword - high speed usb extender
- usb 2.0 extender
- usb cat5 extender
- usb cat6 extender
- usb extender
- usb utp extender
- 4 port usb extender
- 4-port
- USB2004EXT
- USB2004EXTGB
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
System and Cable Requirements USB enabled computer system with available USB port Accessory Products - USB2HAB1
- USB2HAB3
- USB2HAB6
- USB2HAB10
- USB2HAB15
- USB3SEXT6BK
- USB3SEXT1MBK
- USB3SEXT2MBK
- N6PATCH6BL
- N6PATCH10BL
- N6PATCH15BL
- N6PATCH20BL
- N6PATCH25BL
- N6PATCH30BL
- N6PATCH35BL
- N6PATCH50BL
- N6PATCH75BL
- N6PATCH100BL
- N6PATCH125BL
- N6PATCH150BL
Related Products - USB2G4LEXT2
- USB2002EXT2
- USB110EXT2
- USB2001EXT2
- USB2001EXT2P
- USB2001EXTV
- USB1000IP
Input Current 0.58 A Input Voltage 100 - 240 AC Output Current 1A Output Voltage (V) 24 DC Power Consumption (In Watts) 15 Power Source AC Adapter Included Plug Type M Center Tip Polarity Positive Color Black Humidity 10~90% RH Material Aluminum and Plastic Operating Temperature 0°C to 50°C (32°F to 122°F) Product Length (mm) 100.000 Product Width (mm) 76.000 Product Height (mm) 26.000 Product Weight (g) 600.000 Storage Temperature -20°C to 70°C (-4°F to 158°F) TAA Compliant No Maximum Cable Length (mm) 100000 Maximum Data Transfer Rate 480 Mbps OS Compatibility OS Independent Cabling Cat 5 UTP LED Indicators - 1 - Link
- 1 - Host Connection
- 1 - Activity
- 1 - Power
- 4 - USB Link
Carton Depth (mm) 196 Carton Height (mm) 107 Carton Quantity 28 Carton Weight Gross (g) 14890 Included in Package - 1 - universal power adapter
- 1 - quick-start guide
- 1 - USB 2.0 extender local unit
- 1 - USB 2.0 extender remote unit
- 1 - 6 ft [1.8 m] USB cable
- 1 - mounting kit
- 5 - power cords (NA, JP, EU, UK, ANZ)
Package Depth (mm) 195 Package Height (mm) 110 Package Width (mm) 245 Package Quantity 1 Package Weight (g) 1300 Packaging Description 4 Port USB 2.0 Extender over Cat5/Cat6 Packaging Description India 4 Port USB 2.0 Extender over Cat5/Cat6 Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 USB-A (480Mbps, 2.5W) Connector 1 (Quantity) 4 Connector 2 RJ-45 Connector 2 (Quantity) 1 Host Connector 1 USB-B (480Mbps, 2.5W) Host Connector 1 (Quantity) 1 Host Connector 2 RJ-45 Host Connector 2 (Quantity) 1 Amazon Merchandising Manager Veronica Ye Artwork Due Date 2014-06-18 Digital Content Due Date 2016-12-28 Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Graphic Designer Shane Arnett Launch Markets (concatenated) AU,CA,CL,EU,JP,UK,US Primary Technology None Product Development Specialist Ray Aoki Product Information Creation Specialist (PICS) Alex Garcia Product Manager Natalie Goodale Product Performance Specialist Aaron Bens Product Photographer Alejandra Valencia Tech Lead Brian Linseman Technical Writer Alex Garcia Technology Lifecycle None
