USB3AAEXT3M
3 m USB 3 0 Active Extension Cable M F
Extend the distance of a USB 3.2 Gen1 device an additional 3 meters
Main Image
Product Images
Product Images
Product Images
Product Images
Product Images
Product Name 3 m USB 3 0 Active Extension Cable M F Product Number USB3AAEXT3M UPC 065030846295 Lifecycle status Active Warranty 2 Years Taxonomy Product > Cables > USB & Thunderbolt Cables Category Level 1 USB and Thunderbolt Cables Category Level 2 USB-A Cables Category Level 3 USB-A Extension Cables - 5Gbps Active Family USB Extension Cables Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) XXXXXX054X Country of Origin History (2) China Country of Origin Revision (2) XXXXXX042X Product Title (Short) 3m USB 3.0 Active Extension Cable M/F Product Title (Standard) 3m USB 3.0 (5Gbps) Active Extension Cable, M/F, TAA Product Title (Long) 3m USB 3.0 (5Gbps) Active Extension Cable - M/F - TAA Product Title (AMZ) 3m USB 3.0 (5Gbps) Active Extension Cable - M/F - 3m USB 3.0 Extension Cable - USB 3.0 repeater Cable , TAA (USB3AAEXT3M) Title Ingram (Part 1) 3m USB 3.0 Active Extension Cabl Title Ingram (Part 2) e - M/F Website Product Headline Extend the distance of a USB 3.2 Gen1 device an additional 3 meters Bullet 1 Fully shielded for error-free connections Bullet 2 USB bus-powered Bullet 3 Plug-and-play, no driver required Bullet 4 Blue LED indicator x1 for Extension Cable and USB port connection status monitoring Bullet 5 Universal external power source also included Bullets (Consolidated) M/F - USB extension cable - USB Type A (M) to USB Type A (F) - USB 3.0 - 10 ft - active - black - for P/N: PEXUSB3S44V Marketing Copy Applications - Cascade up to 4 levels
- Backwards compatible with USB 2.0/1.1 devices
- Extend the distance of USB peripherals beyond the USB 3.0 3-meter limitation
Website Search Keyword - USB Extender
- active usb cable
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- UKCA - Environmental - United Kingdom - UK Restriction of Hazardous Substances (RoHS) 2012
- EU RIC + Italian Sorting - Packaging - Waste - European Union - Corrugated Fiberboard
- Triman/Info-Tri - Product - Waste - European Union - EEE Device + accessories + cords
- Recycling - Waste - Japan - Paper Recycling Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- Triman/Info-Tri - Packaging - Waste - European Union - Paper Box + paper tray/divider
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
Special Notes Cascade up to 4 USB3AAEXT3M devices together for further extension Accessory Products - USB3SAB10
- SVA5H2NEUA
Related Products - USB3AAEXT5M
- USB3AAEXT10M
Input Current 0.35 A Input Voltage 100 - 240 AC Output Current 2A Output Voltage (V) 5 DC Power Consumption (In Watts) 10 Power Source AC Adapter Included Plug Type H Center Tip Polarity Positive Cable Length (mm) 3000 Color Black Primary Material Plastic Product Length (mm) 86.5 Product Width (mm) 22 Product Height (mm) 12 Product Weight (g) 147 TAA Compliant Yes OS Compatibility OS Independent Cable Jacket Material PVC - Polyvinyl Chloride Chipset ID VIA VL210 Connector Plating Nickel Connectors Combo USB-A to USB-A Host or Charger Connector USB-A Peripheral Connector USB-A Carton Depth (mm) 414 Carton Height (mm) 317 Carton Quantity 28 Carton Weight Gross (g) 11244 Included in Package - 1 - 3 m USB 3.0 Active Extension Cable - M/F
- 1 - Universal Power Adapter
- 1 - Plug Adapters for North America, UK, Europe, and Australia
Package Depth (mm) 147 Package Height (mm) 52 Package Width (mm) 232 Package Quantity 1 Package Weight (g) 370 Packaging Description 3m (10ft) USB 5Gbps Active Extension Cable - M/F Packaging Description India 3m (10ft) USB 5Gbps Active Extension Cable - M/F Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 USB-A (5Gbps, 4.5W) Connector 1 (Quantity) 1 Connector 2 USB-A (5Gbps, 4.5W) Connector 2 (Quantity) 1 Amazon Merchandising Manager Veronica Ye Artwork Due Date 2014-06-18 Buying Center - AV & Collaboration Yes Buying Center - Data Center No Buying Center - End User Compute Yes Buying Center - Networking & Edge Yes Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,BE,CA,CH,DE,DK,ES,EU,FR,IE,IT,JP,MX,NL,SE,UK,US Primary Technology None Product Development Specialist David Bromley Product Information Creation Specialist (PICS) Brian Chan Product Manager Tim North Product Performance Specialist Aaron Bens Product Photographer Caleigh Le Grand Tech Lead Justin Weaver Technical Writer Brian Chan Technology Lifecycle Mainstream
