Main Image
USB6N1DOCK
Main Image
Product Images
Product Images
Product Images
Product Images
Product Images
Product Images
Product Name 6-in-1 USB 2.0 Notebook Port Replicator Product Number USB6N1DOCK UPC 065030799157 Lifecycle status Discontinued Warranty 2 Years Taxonomy Product > Legacy Discontinued Category Level 1 Legacy Category Category Level 2 Legacy Sub-Category Category Level 3 Legacy Group Country of Origin Europe & Japan China Country of Origin North America China Product Title (Short) 6-in-1 USB 2.0 Docking Station Product Title (Standard) StarTech.com 6-in-1 USB 2.0 Docking Station / Port Replicator - Port replicator Product Title (Long) 6-in-1 Black USB 2.0 Laptop Docking Station with Port Replicator Title Ingram (Part 1) 6-in-1 USB 2.0 Laptop Docking St Title Ingram (Part 2) ation with Port Replicator Bullet 1 Adds a Parallel, Serial, 10/100 Mbits/sec Ethernet LAN, PS/2 Keyboard/Mouse and two USB 2.0 ports to your laptop or desktop system Bullet 2 Occupies only one USB port, while providing ample connectivity Bullet 3 Backward compatible with USB 1.1 devices Bullet 4 Users can add on/daisy chain additional hubs or docking stations for increased connectivity Bullet 5 Easy Plug and Play installation Marketing Copy Applications - Connect serial, parallel, USB, Ethernet and PS/2 devices to your system
- Has the ability to create a direct USB-to-USB data exchange channel between two computers
System and Cable Requirements 1 x Free USB port Accessory Products - USB2HAB10T
- USB2HAB15T
- USB2HAB6T
- USB2HAB6
- USB2HAB15
- USB2HAB10
- M45PATCH10BL
- M45PATCH15BL
- M45PATCH25BL
- M45PATCH50BL
- SC10FF
- SC10MF
- SC6MF1284
- SC6MM1284
- KXT102
- KXT102_10
- KXT102_15
- KXT102_25
- KXT102_50
- KXT102MM
- KXT102MM_15
- KXT102MM_25
- KXT100MM
- KXT101
Related Products - ICUSB232
- ICUSB1284D25
- USB2PS2
- USB5N1DOCK
Power Source AC Adapter Included Center Tip Polarity Positive Color Black Material Plastic Operating Temperature 0 to 50 Product Length (mm) 178 Product Width (mm) 55 Product Height (mm) 25 Product Weight (g) 160 Storage Temperature -20 to 70 TAA Compliant No General Specifications Power: Bus Powered or Self Powered OS Compatibility - Windows Vista
- Windows 2000
- Windows XP
- Windows 7
- Windows Server 2008 R2
Industry Standards - USB 2.0
- IEEE 1294
- IEEE 802.3
- USB 1.1
Carton Depth (mm) 314 Carton Height (mm) 412 Carton Quantity 20 Carton Weight Gross (g) 12800 Package Depth (mm) 78 Package Height (mm) 147 Package Width (mm) 232 Package Weight (g) 580 Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 USB-A (480Mbps, 2.5W) Connector 1 (Quantity) 1 Connector 2 USB-B (480Mbps, 2.5W) Connector 2 (Quantity) 1 Connector 3 USB-A (480Mbps, 2.5W) Connector 3 (Quantity) 2 Connector 4 DB-25 Parallel / Serial Connector 4 (Quantity) 1 Connector 5 DB-9 Serial Connector 5 (Quantity) 1 Connector 6 PS/2 Connector 6 (Quantity) 2 Connector 7 RJ-45 Connector 7 (Quantity) 1 en-US Content Approved Yes Product Manager Carey Cline
