USBBT1EDR4
Mini Bluetooth Dongle Class 1 USB Bluetooth 4 0
Add Bluetooth 4.0 capabilities to a laptop or desktop computer through USB
Main Image
Product Images
Product Images
Product Images
Product Images
Product Images
Product Images
Product Images
Quick-Start Guide
Product Name Mini Bluetooth Dongle Class 1 USB Bluetooth 4 0 Product Number USBBT1EDR4 UPC 065030852920 Lifecycle status Active Warranty 2 Years Taxonomy Product > Cards & Adapters > Network Cards & Adapters Category Level 1 Networking Category Level 2 Laptop Network Adapters Category Level 3 Bluetooth Adapters Family Classic Connect Bluetooth Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) Taiwan Country of Origin Revision (1) XXXXXX024X Country of Origin History (2) China Country of Origin Revision (2) XXXXXX159X Product Title (Ultra-Short) USB Bluetooth 4 Adap Product Title (Short) Mini USB Bluetooth 4.0 Dongle - 50m Product Title (Standard) Mini USB Bluetooth 4.0 Adapter - 50m(165ft) Class 1 EDR Wireless Dongle Product Title (Long) Mini USB Bluetooth 4.0 Adapter - 50m (165ft) Class 1 EDR Wireless Dongle Product Title (AMZ) Bluetooth Adapter - Mini Bluetooth 4.0 USB Adapter - 50m/165ft Wireless Bluetooth Dongle - Smart Ready LE+EDR (USBBT1EDR4) Title Ingram (Part 1) Mini Bluetooth Dongle - Class 1 Title Ingram (Part 2) USB Bluetooth 4.0 Low Energy Website Product Headline Add Bluetooth 4.0 capabilities to a laptop or desktop computer through USB Bullet 1 PORTABLE DESIGN: This Bluetooth class 1 adapter features a lightweight design that conveniently fits into your laptop PC carrying case, making it ideal for professionals on the go Bullet 2 RELIABLE CONNECTION: For a secure and reliable connection, the Bluetooth USB adapter is Bluetooth Smart Ready enabling you to connect to the latest Apple and Android smartphones and tablets Bullet 3 TRANSFER DISTANCE: The Bluetooth dongle provides a secure wireless connection with support for transfer distances up to 50m / 165ft Bullet 4 BLUETOOTH 4.0 LE COMPLIANT: The USB Bluetooth receiver offers data transfer rates up to 3 Mbps and low power consumption; The adapter also integrates added security for all transfers using 128-bit AES encryption Bullet 5 ADD BLUETOOTH CAPABILITIES: This BT4 adapters lets you add Bluetooth 4.0 capabilities to your computer or laptop through the USB port of your device; Natively supported on Windows and Mac with no additional software required Bullets (Consolidated) Add Bluetooth 4.0 capabilities to your laptop or desktop computer through USB - Mini USB Bluetooth 4.0 Adapter/50m (165ft) Class 1 EDR Wireless Dongle - Bluetooth 4.0 LE compliant Bluetooth Smart Ready transceiver - Supports Enhanced Data Rate (EDR) with data transfer rates up to 3 Mbps - Ultra-compact form factor and Low-power consumption - Mini Bluetooth Dongle/Bluetooth Smart Ready/LE+EDR/Class 1 EDR Bluetooth Wireless Adapter/Bluetooth 4.0 Low Energy Marketing Copy Marketing Copy (No HTML) Applications - Connect Bluetooth peripherals such as keyboard/mouse or smart phones to your computer system
- Reduce cable clutter by using wireless Bluetooth devices (such as keyboard/mouse) instead of traditional wired devices
- Connect peripherals wirelessly to a computer in a remote/secure location
- Connect peripherals in an industrial setting where the computer can be kept away from the work areas
Website Search Keyword U261-001-BT4 Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- CE - IR - Wireless - European Union - EU Radio Equipment Directive (RED) Short-Form DoC
- ISED - IR - Wireless - Canada - Industry Canada (IC) Wireless ID
- FCC - IR - Wireless - United States - FCC Part 15, Subpart C
- Recycling - Waste - Japan - Plastic Recycling Mark
- Recycling - Waste - Japan - Paper Recycling Mark
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
Special Notes Ranges above 10 meters (32.8 ft) require the connected Bluetooth device to support Bluetooth Class 1 System and Cable Requirements Available USB port Related Products - USBBT2EDR2
- USBBT1EDR2
- USB2IR3
Power Source USB-Powered Color Black Humidity 0~75% RH Material Plastic Operating Temperature -10°C to 50°C (14°F to 122°F) Primary Material Plastic Product Length (mm) 22.4 Product Width (mm) 14.8 Product Height (mm) 7.4 Product Weight (g) 2.000 Storage Temperature -20°C to 70°C (-4°F to 158°F) TAA Compliant No Frequency 2.402-2.48GHz ISM Band Max Distance 50m [164ft] Maximum Data Transfer Rate 3 Mbps MTBF (hours) 187,730 hours OS Compatibility - Mac OS X Mavericks (10.9)
- Windows 8
- Windows 7
- Windows 10
- Mac OS X El Capitan (10.11)
- macOS Sierra (10.12)
- Windows Server 2016
- macOS High Sierra (10.13)
- macOS Mojave (10.14)
- Windows Server 2019
- macOS Catalina (10.15)
- macOS Big Sur (11.0)
- Windows 11
- macOS Monterey (12.0)
- macOS Ventura (13.0)
- Windows Server 2022
- macOS Sonoma (14.0)
- macOS Sequoia (15.0)
- macOS Tahoe (26.0)
Bus Type USB 2.0 Chipset ID CSR8510A10 Industry Standards Bluetooth v4.0, v3.0, EDR LED Indicators 1 - Power / Standby / Link Carton Depth (mm) 500 Carton Height (mm) 384 Carton Quantity 60 Carton Weight Gross (g) 4146 Included in Package - 1 - USB Bluetooth Adapter
- 1 - Quick Start Guide
Package Depth (mm) 170 Package Height (mm) 32 Package Width (mm) 143 Package Quantity 1 Package Weight (g) 58 Packaging Description USB to Bluetooth 4.0 Adapter - 50m Class 1 Packaging Description India USB to Bluetooth 4.0 Adapter - 50m Class 1 Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 USB-A (480Mbps, 2.5W) Connector 1 (Quantity) 1 Connector 2 Bluetooth Class 1.0 (100m) Connector 2 (Quantity) 1 Amazon Merchandising Manager Kathleen Marshall Artwork Due Date 2013-07-29 Buying Center - AV & Collaboration No Buying Center - Data Center No Buying Center - End User Compute Yes Buying Center - Networking & Edge Yes Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,BE,CA,CH,DE,DK,ES,EU,FI,FR,HK,IE,IT,NL,SE,UK,US Primary Technology None Product Development Specialist Ray Aoki Product Information Creation Specialist (PICS) Alex Garcia Product Manager Rob Fleck Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Tech Lead Stefan Tirolese Technical Writer Andrew Richardson Technology Lifecycle Legacy
