USBBT2EDR4
USB Bluetooth Dongle - Class 2 USB Bluetooth v4 LE
Add Bluetooth 4.0 capabilities to a laptop or desktop computer through USB
Main Image
Product Images
BOM Image
Product Name USB Bluetooth Dongle - Class 2 USB Bluetooth v4 LE Product Number USBBT2EDR4 UPC 065030855198 Lifecycle status Active Warranty 2 Years Taxonomy Product > Cards & Adapters > Network Cards & Adapters Category Level 1 Networking Category Level 2 Laptop Network Adapters Category Level 3 Bluetooth Adapters Family Classic Connect Bluetooth Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) XXXXXX003X Product Title (Ultra-Short) USB Bluetooth 4 Adap Product Title (Short) USB Bluetooth 4.0 Adapter - 10m Class 2 Product Title (Medium) Mini USB Bluetooth 4.0 Adapter - 10m (33ft) Class 2 EDR Wireless Dongle Product Title (Standard) Mini USB Bluetooth 4.0 Adapter, 10m (33ft) Class 2 EDR Wireless Dongle, TAA Product Title (Long) Mini USB Bluetooth 4.0 Adapter - 10m (33ft) Class 2 EDR Wireless Dongle - TAA Product Title (AMZ) Mini USB Bluetooth 4.0 Adapter - 10m (33ft) Class 2 EDR Wireless Dongle - USB Bluetooth Dongle - Bluetooth Smart Ready LE+EDR , TAA (USBBT2EDR4) Title Ingram (Part 1) USB Bluetooth Dongle - Class 2 Title Ingram (Part 2) USB Bluetooth 4.0 Low Energy Website Product Headline Add Bluetooth 4.0 capabilities to a laptop or desktop computer through USB Bullet 1 Bluetooth® 4.0 LE +EDR compliant Bluetooth Smart Ready transceiver Bullet 2 Low power consumption Bullet 3 Backward compatible with Bluetooth v3.0, 2.x and 1.x devices Bullet 4 Class 2 device with 10m (33ft) effective range Bullet 5 Ultra-compact form factor Bullets (Consolidated) Add Bluetooth 4.0 capabilities to a laptop or desktop computer through USB - Mini USB Bluetooth 4.0 Adapter - 10m (33ft) Class 2 EDR Wireless Dongle - USB Bluetooth Dongle - USB Bluetooth Adapter - Bluetooth Smart Ready LE +EDR - Bluetooth 4 Low Energy Marketing Copy Applications - Connect Bluetooth peripherals such as keyboard/mouse sets, smart phones, headphones / headsets and healthcare equipment to your computer system
- Connect peripherals wirelessly to a computer in a remote/secure location
- Reduce cable clutter by using Bluetooth wireless technology instead of traditional wired devices
- Connect peripherals in an industrial setting where the computer can be kept away from the work areas
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- ISED - IR - Wireless - Canada - Industry Canada (IC) Wireless ID
- FCC - IR - Wireless - United States - FCC Part 15, Subpart C
- Recycling - Waste - Japan - Plastic Recycling Mark
- Recycling - Waste - Japan - Paper Recycling Mark
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
System and Cable Requirements Available USB port Related Products - USBBT1EDR4
- USBBT1EDR2
- BT2A
- USBBT2EDR2
- USB2IR3
Constrained SKU Alternatives (Limited Stock) USBBT1EDR4 Power Source USB-Powered Color Black Humidity 0~90% RH Material Plastic Operating Temperature -10°C to 50°C (14°F to 122°F) Primary Material Plastic Product Length (mm) 19.000 Product Width (mm) 15.000 Product Height (mm) 6.000 Product Weight (g) 2.500 Storage Temperature -20°C to 70°C (-4°F to 158°F) TAA Compliant Yes Frequency 2.4GHz ~ 2.4835GHz Max Distance 10m [33ft] Maximum Data Transfer Rate 3 Mbps OS Compatibility - Windows 8
- Windows 7
- Mac OS X El Capitan (10.11)
- Windows 10
- macOS Sierra (10.12)
- macOS High Sierra (10.13)
- macOS Mojave (10.14)
- macOS Catalina (10.15)
- macOS Big Sur (11.0)
- Windows 11
- macOS Monterey (12.0)
- macOS Ventura (13.0)
- macOS Sonoma (14.0)
- macOS Sequoia (15.0)
- macOS Tahoe (26.0)
Bus Type USB 2.0 Chipset ID Broadcom - 20702 Industry Standards Bluetooth v4.0, v2.1, EDR Carton Depth (mm) 334 Carton Height (mm) 212 Carton Quantity 20 Carton Weight Gross (g) 2738 Included in Package - 1 - USB Bluetooth Adapter
- 1 - Driver CD
- 1 - Instruction Manual
Package Depth (mm) 142 Package Height (mm) 32 Package Width (mm) 174 Package Quantity 1 Package Weight (g) 158 Packaging Description USB to Bluetooth 4.0 Adapter - 10m Class 2 Packaging Description India USB to Bluetooth 4.0 Adapter - 10m Class 2 Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 USB-A (480Mbps, 2.5W) Connector 1 (Quantity) 1 Connector 2 Bluetooth Class 2 (10m) Connector 2 (Quantity) 1 Amazon Merchandising Manager Kathleen Marshall Artwork Due Date 2013-10-09 Buying Center - AV & Collaboration No Buying Center - Data Center No Buying Center - End User Compute Yes Buying Center - Networking & Edge Yes Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,CA,CH,DE,IE,US Primary Technology None Product Development Specialist Ray Aoki Product Information Creation Specialist (PICS) Alex Garcia Product Manager Rob Fleck Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Tech Lead Stefan Tirolese Technical Writer Andrew Richardson Technology Lifecycle Mainstream
