W31C-4100-POWER-CORD
NEMA 5-15R to NEMA L5-15P - Heavy-Duty, 15A, 125V, 14 AWG, 1
Extend a power connection or connect to a PDU with a cable that's designed for heavy use
Main Image
Product Images
Product Images
Product Images
Video Link YouTube
Product Name NEMA 5-15R to NEMA L5-15P - Heavy-Duty, 15A, 125V, 14 AWG, 1 Product Number W31C-4100-POWER-CORD UPC 065030901475 Lifecycle status Active Warranty Lifetime Weighted Opportunity 18748 Taxonomy Product > Cables > Power Cables Category Level 1 Cables - Other Category Level 2 Power Cables Category Level 3 External Power Cords Family L5-20P to 5-15 Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) XXXXXX120X Product Title (Ultra-Short) AC Power Cord Product Title (Short) 1ft Power Cord, L5-15P to 5-15R Product Title (Medium) 1ft (30cm) Heavy Duty Power Cord, NEMA L5-15P to NEMA 5-15R, 15A 125V Product Title (Standard) 1ft (30cm) Heavy Duty Power Cord, Twist-Lock NEMA L5-15P to NEMA 5-15R, 15A 125V, 14AWG, UL Listed, TAA Product Title (Long) 1ft (30cm) Heavy Duty Power Cord, Twist-Lock NEMA L5-15P to NEMA 5-15R Black Adapter Cord, 15A 125V, 14AWG, Heavy Gauge Plug Converter Cable, TAA Compliant, UL Listed Product Title (AMZ) 1ft (30cm) Heavy Duty Power Cord, Twist-Lock NEMA L5-15P to NEMA 5-15R Black Adapter Cord, 15A 125V, 14AWG, Heavy Gauge Plug Converter Cable - UL Listed , TAA (W31C-4100-POWER-CORD) Title Ingram (Part 1) 30cm Heavy Duty Power Cord Title Ingram (Part 2) NEMA L5-15P to 5-15R, 15A 125V Website Product Headline Extend a power connection or connect to a PDU with a cable that's designed for heavy use Bullet 1 HEAVY DUTY ADAPTER CABLE: 1ft (30cm) Adapter Power Cable with Twist-Lock NEMA L5-15P to NEMA 5-15R connector works with servers or high-power equipment; Locking L5-15 plug securely attaches to an outlet or power source; Indoor use; Rated up to 125V at 20A Bullet 2 BUILT FOR PERFORMANCE AND SAFETY: UL Listed; VW-1 Fire Rated cable with fully molded connector strain reliefs for durability; 3-conductor power cable made with 100% copper wire Bullet 3 SPECS: 1ft (30cm); TAA Compliant; Twist-Lock NEMA L5-15P to NEMA 5-15R; 14AWG; 125V 15A (Max); Jacket Rating: SJT; Color: Black; Temperature Range: -4°F to 221°F (-20℃ to 105℃); Cable O.D.: 0.36in (9.3mm) Bullet 4 COMPATIBILITY: NEMA L5-15P to NEMA 5-15R power cord works with North American PDUs and high-powered devices; Convert a NEMA L5-15 outlet to 5-15R for convenient integration with servers, switches, or UPS; Heavy duty adapter power cord Bullet 5 THE IT PRO’S CHOICE: Designed and built for IT Professionals, the heavy duty adapter power cord is backed for life, including free lifetime 24/5 multi-lingual technical assistance; This adapter power cable is available in other plug configurations Bullets (Compact) 1ft heavy duty power cord with IEC NEMA L5-15P to NEMA 5-15R connectors; 125V at 15A; UL Listed; Wire: 100% Copper; Fire Rating: VW-1; 14AWG; Jacket Rating: SJT; Temp Range: -4 to 221°F; Cable O.D.: 0.44in; TAA Compliant Bullets (Consolidated) 1ft (30cm) Heavy duty power cord with Twist-Lock NEMA L5-15P to NEMA 5-15R connectors; Rated up to 125V at 20A (Max) - UL Listed; Durable molded connectors w/strain reliefs; 100% Copper wire; Fire Rating: VW-1 - 14AWG; Jacket Rating: SJT; Temperature Range: -4 to 221 DEGF; Cable O.D.: 0.44in - TAA Compliant; Twist-Lock NEMA L5-15P connects securely to a wall outlet or power source; NEMA 5-15R receptacle works with North American servers and rackmount power connections Marketing Copy Marketing Copy (No HTML) Our power cables are the preferred choice for IT professionals, tailored to meet the specific demands of IT applications. Our comprehensive range includes standard and heavy-duty power cords, extension cords, medical-grade cords, splitter cables, and passthrough options. We prioritize safety, and reliability through rigorous in-house and third-party testing. Our cables are certified for both performance and safety, constructed using UL-listed components compliant with UL62 and UL817 standards. They also adhere to environmental safety standards, including REACH and RoHS compliance. We use 100% copper wiring that undergoes thorough testing for continuity and conductivity, guaranteeing maximum performance and reliability. Our cables are further tested in temperature chambers to ensure they meet environmental and jacket ratings. Backed for life with 24-hour, five day-a-week support from qualified Technical Advisor and our IT Pro community forums, our brand is trusted throughout the IT ecosystem and used by over 80% of Fortune 500 companies Applications - Heavy Duty power cord supports high-powered equipment and PDUs
- Extend a server or rackmount equipment power cord by an additional 2ft
Website Search Keyword - Heavy Duty Power Cable
- Heavy Duty Power Cord
- L5-15P to 5-15R Power Cable
- L5-15P to 5-15R Power Cord
Required Regulatory Compliance Marks - UL - Safety - Electrical - Canada / United States - Enhanced UL Mark
- Recycling - Waste - Japan - Paper Recycling Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
Output Current 15A Cable Length (mm) 305 Cable OD 9.3 Color Black Humidity 0% to 65% RH Operating Temperature -20° to 105°C (-4° to 221°F) Product Length (mm) 305.000 Product Width (mm) 39.000 Product Height (mm) 39.000 Product Weight (g) 162.000 Storage Temperature -20° to 105°C (-4° to 221°F) TAA Compliant Yes Wire Gauge 14 AWG Features Locking Connector Maximum Cable Length (mm) 305 Voltage Rating 125V Cable Jacket Material PVC Cable Type SJT Connector Plating Nickel Female Connector 5-15R Fire Rating VW-1 Rated Male Connector / Plug L5-15P Number of Conductors 3 Type AC Power Cord Carton Depth (mm) 497 Carton Height (mm) 271 Carton Quantity 100 Carton Weight Gross (g) 18116 Included in Package 1 - 1ft NEMA 5-15R to NEMA L5-15P Heavy-Duty Power Cord Package Depth (mm) 145 Package Height (mm) 42 Package Width (mm) 174 Package Weight (g) 176 Packaging Description Heavy-Duty Power Cord - NEMA 5-15R to NEMA L5-15P - 1ft (0.3m) Black Packaging Description India Heavy-Duty Power Cord - NEMA 5-15R to NEMA L5-15P - 1ft (0.3m) Black Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 NEMA L5-20P (125V AC, 20A) Connector 1 (Quantity) 1 Connector 2 NEMA 5-15 (125V AC, 15A) Connector 2 (Quantity) 1 A+ Required Actual Inbox Documents Created None Amazon Merchandising Manager Veronica Ye Application Photos Required Artwork Due Date 2023-06-16 Buying Center - AV & Collaboration No Buying Center - Data Center Yes Buying Center - End User Compute No Buying Center - Networking & Edge Yes Comparable SKU Comment Not same, but close. Comparable SKU 2 Comment NA Digital Content Due Date 2023-10-10 Enhanced Gallery Not Required Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett ID Label Silkscreened or a Label No ID label Launch Markets (concatenated) CA,US Product Development Specialist Alex Sikora Product Information Creation Specialist (PICS) Brian Chan Product Manager Tim North Product Performance Specialist Ray Aoki Product Photographer Shane Arnett Target Development Completion Date 2023-06-09 Target Production Release 2023-07-15 Tech Lead Justin Weaver Technical Writer Brian Chan Technology Lifecycle Mainstream Video Not Required
