CRC Dielectric Grease 1X10OZ
Main ImageDownload

CRC Dielectric Grease 1X10OZ

CRC Dielectric Grease

  • Item Number1003346
    Case Number1003345
    Legacy Number03082
    Product DescriptionNon-curing silicone compound used for electrical sealing, lubricating, protecting and insulating. Waterproofs electrical connections and components. Improves electrical performance in adverse weather conditions.
    ApplicationsElectrical panels, outdoor lighting, scoreboards, traffic lights, high voltage poles, transformers, disconnects, switching mechanisms, electrical contacts, spark plugs, battery terminals, and fasteners.
    Unit Package Description16 Ounce Aerosol
    BrandCRC
    Net Fill10 wt oz
    UPC Code078254030821
    Unit Dimensions7.75H x 2.63W x 2.63D in
    Units Per Case12
    Case Dimensions8.1H x 8.3W x 11.1D in
    AppearanceTranslucent to Opaque Gel Paste
    Base TypeSilicone
    Flash point (F)<20°F
    Flash point (C)<-7°C
    Flammability Class - CPSCNot a Consumer Product
    Spec Gravity Concentrate0.646
    KB ValueN/A
    Plastic SafeNot Plastic Safe
    Film TypeNon-Curing Silicone Paste
    Film ThicknessN/A
    Evaporation RateFast
    Dielectric Strength13,960 Volts
    Timken Ok Load (lbs)N/A
    PropellantHydrocarbon
    NSF Category CodeH1
    NSF Number130627
    Aerosol Flammability LevelII
    DOT Proper Shipping NameAerosols, Flammable, Limited Quantity
    4 Ball EPN/A
    4 Ball WearN/A
    Drop PointN/A
    pHN/A
    ISO Viscosity GradeN/A
    NLGI Grade2
    SAE GradeN/A
    Water WashoutN/A
    Working Temp (F)-70 to 400°F
    Working Temp (C)-56.7 to 204.4°C
    VOC % (Consumer Product def)90.1
    VOC g/L (Consumer Product def)582
    VOC lbs/gal (Consumer Prod def)4.85
    VOC CategoryMulti-Purpose Lubricant
